Addi-Data APCI-3010 Technical Description page 22

Connecting the peripherals
Table 7-1: Connection of the digital inputs and
Pin description
+24 V
Output channel 0
Output channel 1
Output channel 2
Output channel 3
Input channel 0 (-)
Input channel 0 (+)
Input channel 1 (-)
Input channel 1 (+)
Input channel 2 (-)
Input channel 2 (+)
Input channel 3 (-)
Input channel 3 (+)
GND 0
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
TTL channel 0
TTL channel 1
TTL channel 10
TTL channel 11
22
outputs (24 V and TTL)
FB8001
Pin No.
(50-pin SUB-D
male connector)
38
4
3
2
1
21
37
20
36
19
35
18
34
5
22
6
39
23
7
40
24
8
41
25
50
49
31
30
Board
Pin No.
(50-pin header)
14
10
7
4
1
12
11
9
8
6
5
3
2
13
15
16
17
18
19
20
21
22
23
24
50
47
42
39
APCI-3xxx
