Technical data
Logic output level:
UH (typ.) ....................................................3.3 V at I
UH (min.) ...................................................2.4 V at I
UL (max.)...................................................0.55 V at I

4.3.6 Timer, counter and watchdog

Timer, interruptible:
Number: ....................................................3
Timer depth: ..............................................16-bit
Time base: .................................................µs, ms, s (programmable)
Output: .......................................................Low/High (programmable)
Counter, interruptible:
Number: ....................................................3
Resolution: ................................................16-bit
Input: ..........................................................Low/High (programmable)
Output: .......................................................Low/High (programmable)
Operation mode:.........................................Mode 2, Mode 3 (programmable)
Watchdog:
Number (APCI-3010, APCI-3016):..........1
Number (APCI-3110, APCI-3116):..........2
Watchdog depth: .......................................16-bit
Programmability: .......................................1 μs to 65535 s
Time base: ................................................. µs, ms, s (programmable)
Monitoring period: .................................... 1 to 4095 µs, ms, s
Tolerance:................................................... ≤ 1 µs, ms, s
16
APCI-3xxx
= - 100 μA
out
= -20 mA
out
= 20 mA
out
