Tinycontrol LAN Controller V2.0 Manual page 5

PINS and COMPONENTS DESCRIPTION
Power
max 28V
green LED
Ethernet
10Mbit.
PoE max 28V
orange LED
INP6 - RJ11-
bus
1-Wire for
DS18B20
RESET
Temp. board sensor
PIN / Component
Power
power LED
relay LED
green LED
orange LED
IDC10-1
IDC10-2
INP1÷4D
INP4D
INP1
INP2
INP3
GND
OUT5
GND
NC
C
NO
manual LAN Controller V2.0 – Firmware: HOME v. 3.13 and ISP v. 2.09 – LANKONT-002
IDC10-2
Power supply 8V ÷ 28V DC
Shine LED means power on board
Shine means relay active
Shine LED means eth link active
Shine means data transmitted
Additional outputs, for example, relays
Additional Inputs / Outputs PWM1÷3
Logical inputs Low=0~0,8V, High=0,8V~20V
Also supports a pulse counter
Input for voltage measure 0 ÷ 7.2V (3.6V if jumper on)
Input for voltage meas. 0 ÷ 36V
Input for PT1000 sensor for high temp. measure
General ground
Transistor output (+), voltage = power supply, max 1A
Ground for transistor output (–)
Relay OUT0, normally closed contact
Relay OUT0, common contact
Relay OUT0, normally open contact
www.tinycontrol.eu
IDC10-1 jumper pins
RELAY OUT0
Description
(only v. 3.13)
5
power LED
}
INP1D
INP2D
INP3D
INP4D
GND
INP1 - U 0÷7,2 V
INP2 - U 0÷36 V
INP3 - PT1000
GND
OUT5=Usupply
GND
NC
C
NO
relay LED
