Tinycontrol LAN Controller V2.0 Manual page 20

manual LAN Controller V2.0 – Firmware: HOME v. 3.13 and ISP v. 2.09 – LANKONT-002
5. Watchdog (only v. 2.09)
(max 65535s).
Time to respond is 4 seconds,
after this time if no response
one PING failure is counting.
Then if it happen, during wa-
iting for next respond PINGs to
other IP addresses are not re-
alised. It can stretch watchdog
time to other IP addresses.
Amount PING failures, after
this one of three events will be
happen: set (ON) output, set
(OFF) output reset (ON/OFF)
output on definite time (max
65535s).
Selecting this option forces the watchdog
off when in the Event Table occur off / on
Upon his return to the previous state out-
put watchdog is started automatically.
20
www.tinycontrol.eu
the socket.
