Description of the device

Scope of delivery
• VACUSIP base unit without battery (model 159 010) or with battery (model 159 000)
• Mains adapter
• INTEGRA glass bottle 500 ml with standard GL 45 lid
• GL 45 lid with tube fittings
• Tubing and hydrophobic filter with an additional spare filter
• VACUSIP hand operator
• 8-channel stainless steel tips
• 1-channel stainless steel tip
• 1-channel adapter for disposable tips
6
7
8
2
1
Rear view
12
9
10
11
13
6
1 On/off switch
5
2 Indicator LED
3 Base unit
4
4 Stainless steel rod
5 VACUSIP hand operator
6 Hand operator mount
7 Lid with tube fittings
8 500 ml bottle for liquid collection
3
9 Hydrophobic filter
10 Silicone filter adapter
11 Air outlet
12 Opening to insert stainless steel rod
13 Mains connection socket
