Operation

4.1 Vacuum activation and notes on use
Switch on VACUSIP to start the vacuum pump (the LED lights up green).
Once the vacuum is reached, the pump stops until the vacuum falls below threshold.
VACUSIP switches off automatically after the pump has not been running for 10 minutes
or 40 minutes after initial switch-on. This feature can be temporarily deactivated by
pressing the power button for at least 4 seconds when switching on the instrument. The
power-off function is automatically restored after turning off VACUSIP.
Check the level of liquid in the bottle frequently. The liquid level should never reach the lid.
Prevent liquid or foam overflow from the collection bottle into the filter. In case the filter
gets accidentally wetted or soiled, exchange it immediately or otherwise the retention of
further liquid cannot be guaranteed. Note that the hydrophobic filter holds back aqueous
solutions, whereas retention of apolar liquids is limited.
W
ARNING
When working with dangerous substances, you must comply with the material
safety data sheet (MSDS) and the additionally applicable regulations of trade
associations, health authorities, supervisory offices, etc. In addition, when
working with hazardous volatile substances or biohazardous agents, either
place the VACUSIP inside a biosafety cabinet or connect the instrument's air
outlet (11) to a safety ventilation by means of a tube (ID=4 mm) and an
aspiration needle (Part. No. 155 502).
4.2 Code of indicator LED
LED code
Constantly green
Blinking green
Blinking red once
per second
Blinking red 5 times
per second
Constantly red
Blinking red and green Error in vacuum sensor calibration. Please contact your supplier.
www.integra-biosciences.com
Attach a suitable adapter to the hand operator.
To aspirate press the soft buttons on both sides of the
VACUSIP hand operator.
Meaning
Unit is powered on and no errors occurred.
Battery level low.
Leakage detection. Pump turns off if end vacuum has not been
reached after 5 minutes.
Vacuum generation is too fast (~100 mbar/s). Indicates a
clogged part.
Battery error. Press the power button to continue using the
mains power supply.
