VACUSIP - Operating instructions V04
3.3.4 Connecting the silicone tubing
Place the bottle in the instrument and screw on the green lid with tube fittings (7).
Attach the silicone tubing coming from the filter to the fitting on the lid named "FILTER".
Attach the longer silicone tubing to the fitting in the lid named "LIQ" (liquid) and the other
end to the VACUSIP hand operator (5).
3.3.5 Replacing the battery
8
Unscrew the 5 screws on the bottom of the device with a
Phillips screwdriver nr. 1 and remove the bottom lid.
Unplug the old battery and replace it with an original
INTEGRA Biosciences
Accessories and consumables" on page 14. Make sure that
it is inserted with the correct polarity (+/-).
Place back the battery in the battery compartment with the
wire facing to the inside of the instrument.
Close the bottom lid and fix it with the 5 screws.
rechargeable battery,
INTEGRA Biosciences AG
Installation
see "7
