Chapter 7 Terminal Connections
Software/Firmware
FactoryTalk View Studio
FactoryTalk View Machine Edition Runtime
DeviceNet Module
188
Related Information
For more information on DeviceNet products, refer to these
publications:
• DeviceNet Selection Guide, publication DNET-SG001
• DeviceNet Media Design Installation Guide, publication
DNET-UM072
• DeviceNet Tips & Tricks Brochure, publication DNET-BR003
The Rockwell Automation website
provides information and product descriptions of DeviceNet products.
Under the Products and Services heading, select Communications.
DeviceNet Protocol
The terminals support DeviceNet Scheduled I/O only. This protocol
allows direct connection of field devices such as lights, drives, and
valves. It also provides a control architecture that supports multiple
processors. The DeviceNet network is a trunk/drop or bus-based
network that supports up to 64 nodes and operates at 125, 250, or
500 Kbps.
Compatible DeviceNet Controllers
A terminal with a DeviceNet module communicates with an SLC-500
and PLC-5 (PCCC commands), or a ControlLogix processor (CIP
protocol) using Unscheduled messaging. Supported controllers
include:
• ControlLogix using 1756-DNB module.
• PLC-5 with a 1771-SDN module.
• SLC 5/03 - SLC 5/05 with a 1747-SDN module.
Minimum Requirements
PanelView Plus 700 to 1500
Version 4.0 or later
Version 4.0 or later
2711P-RN10H
http://rockwellautomation.com
PanelView Plus 400 and 600
Version 4.0 or later
Version 4.0 or later
2711P-RN10C
Publication 2711P-UM001I-EN-P - December 2008
