Summary of Contents for Rockwell Automation Allen-Bradley PanelView Plus 7
- Page 1 PanelView Plus 7 Performance Series B Terminals Quick Start...
- Page 2 Note that AC power is not available on Series B terminals. Ensure that you are applying power correctly to the terminal during installation. For detailed instructions on how to install and operate the terminal, see the publications that are listed in Additional Resources. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
-
Page 3: Table Of Contents
Additional Resources ..........23 Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... -
Page 4: Getting Started
3. If you are using a mouse or a keyboard, insert each connector into one of the USB ports located at the bottom of the terminal. Bottom View of PanelView Terminal USB Ports Network Ports DC Power Input Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... -
Page 5: Configure The Terminal
1. On the Calibration Menu screen, tap Touch Screen Calibration. 2. In the Touch Screen Calibration dialog box, tap Yes. 3. On the first calibration screen, calibrate the touch screen boundaries as prompted. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... - Page 6 8. In the Exit Calibration Menu dialog box, tap Yes. The terminal reboots and displays the first Welcome to PanelView Plus screen. 9. Review the information on this screen, and then tap the Next button. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 7 The only requirement for the password is that it must be between 1 and 64 characters. 11. Retype the password in the Confirm password (must match password above) field. 12. Tap Next. The terminal displays the Network Adapters setup screen. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 8 If you need to change your network settings after this initial setup, you can do that in FactoryTalk View ME Station by tapping Terminal Settings [F4] > Networks and Communications > Network Connections > Network Adapters. The terminal restarts and displays the PanelView Plus Firmware Update Utility screen. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
-
Page 9: Update The Firmware
• ControlFLASH USB Storage Device 1. Access the Rockwell Automation Product Compatibility and Download Center (PCDC) at rok.auto/pcdc. 2. On the home page, click Available Versions. 3. Click the Select a Product link, and in the Select a Product dialog box, type PanelView Plus 7 Performance in the search field, and then click the Search button. - Page 10 USB storage device while the file is being copied. Wait until you are prompted to remove the USB storage device. 10. Tap OK when you are ready to continue. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
-
Page 11: Controlflash Client
Compatibility and Download Center (PCDC). Downloading the ControlFLASH Plus or ControlFLASH File 1. Access the Rockwell Automation Product Compatibility and Download Center (PCDC) at rok.auto/pcdc. 2. On the home page, click Available Versions. 3. Click the Select a Product link, and in the Select a Product dialog box, type PanelView Plus 7 Performance in the search field, and then click the Search button. - Page 12 1. After you save the DMK file in the desired Firmware Kits location, launch ControlFLASH Plus. 2. Browse to and select the PanelView Plus 7 Performance Series B terminal (series C if it is a Stainless Steel terminal). Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 13 Getting Started 3. Click Next. 4. Confirm that the information is correct, and then click Flash. A series of status changes occur on the ControlFLASH Plus screen and on the PanelView terminal. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 14 On the PanelView terminal, the status changes to CONNECTED: transferring updates… . Once the firmware file transmission is complete, on the ControlFLASH Plus screen, the Status field displays the Polling for power-up status. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 15 Succeeded message. 5. Click Close, and then click Done. When the firmware update is complete, the terminal reboots and displays moving gears while the update installs. 6. Continue with Enter a Password on page Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 16 3. Select the catalog number of the PanelView Plus 7 Performance Series B terminal that you want to update and click Next. 4. Browse to and select the device to update on the EtherNet/IP™ network and click OK. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
- Page 17 Getting Started 5. Select the firmware revision to install and click Next. 6. Read the Danger information in the Summary dialog, then click Finish. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
-
Page 18: Enter A Password
If you need to change (reset) your password after this initial setup, you can do that in FactoryTalk View ME Station by clicking or tapping Terminal Settings [F4] > Desktop Access Setup > Reset Password [F4]. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... - Page 19 4. Tap the Challenge response field, and type the answer to the challenge question. The response needs to be a minimum of 6 characters. 5. Tap OK. The terminal displays the FactoryTalk View ME Station startup screen. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022...
-
Page 20: Transfer Runtime Files (.Mer)
2. In the Transfer Utility dialog box, click the ellipsis to the right of the Source file field, browse to the location of the .mer file, select the .mer file, and click Open. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... -
Page 21: Removable Storage Device
5. Paste the .mer file into the Runtime folder by using CTRL+V. 6. Insert the removable storage device into the PanelView Plus 7 terminal. 7. Tap Terminal Settings, then choose File Management>Copy Files>Copy Applications. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... -
Page 22: Install The Terminal
Adapter Kit for PanelView 5000 and PanelView Plus 7 Performance Terminals Installation Instructions, publication VIEW-IN002. • PanelView Plus 7 Performance Stainless Steel Terminal Gasket Replacement Kit Installation Instructions, publication 2711P-IN012. • ArmorView Plus 7 Installation Instructions, publication 2711P-IN013. Rockwell Automation Publication 2711P-QS002B-EN-P - April 2022... -
Page 23: Additional Resources
Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Lists the functions of the PanelView Plus 7 Performance Series A terminals that are not included PanelView Plus 7 Performance Series B Terminals in the initial version of the PanelView Plus 7 Performance Series B terminals. Also indicates... - Page 24 At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental compliance information on its website at rok.auto/pec. Allen-Bradley, ControlFLASH, ControlFLASH Plus, expanding human possibility, FactoryTalk, PanelView, and Rockwell Automation are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc.
