3Publication 2711P-UM001I-EN-P - December 2008
The information below summarizes the changes to this manual since
the last revision.
Revision bars, as shown in the margin, identify updated information.
This document includes the following changes.
Topic
Corrected touchscreen stylus tip radius
Added catalog numbers for marine-certified terminals and added
OEM option to catalog number configuration diagram
Updated series information for backlights
Added catalog number 2711P-RGB4 for antiglare overlay for
PanelView Plus 400 color keypad/touch terminal
Corrected temperature range around the terminals in Clearances 36
Corrected panel thickness range for lever position 1
Added battery type and disposal information
Added footnotes to tables regarding maximum cable length for
DH-485 modules
Modified connector pinout diagram
Corrected wiring connections and pinouts in Remote I/O & DH+
depictions
Added message about maximum cable length for DH-485
modules
Added battery disposal information to Maintenance chapter
Added environmental information for Airborne Contaminants
Updated EMC and LVD Directives
Summary of Changes
Page
15, 16, 21, 22, 88
23, 25
26
27
38
153
168, 169, 170
176
178, 182, 183
178
228
230
232
3
