OPERATING DETERMINATIONS
The DMX controller serves for operation of DMX-controlled light effect devices such as LED spot lights, moving heads
and scanners in discotheques or on stage.
Power Supply
•
This product is allowed to be operated with an
alternating current of 100-240 V, 50/60 Hz and was
designed for indoor use only. The occupation of the
connection cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
•
The earth has to be connected! If the device will be
directly connected with the local power supply
network, a disconnection switch with a minimum
opening of 3 mm at every pole has to be included in
the permanent electrical installation. The device must
only be connected with an electric installation carried
out in compliance with the IEC standards. The electric
installation must be equipped with a Residual Current
Device (RCD) with a maximum fault current of 30 mA.
Installation
•
Do not shake the device. Avoid brute force when
installing or operating the device. When choosing the
installation spot, please make sure that the device is
not exposed to extreme heat, moisture or dust. There
should not be any cables lying around. You endanger
your own and the safety of others!
Taking into Operation
•
Operate the device only after having familiarized with
its functions. Do not permit operation by persons not
qualified for operating the device. Most damages are
the result of unprofessional operation!
Ambient Conditions
•
The ambient temperature must always be between
-5° C and +45° C. Keep away from direct insulation
(particularly in cars) and heaters. The relative
humidity must not exceed 50 % with an ambient
temperature of 45° C.
•
This device must only be operated in an altitude
between -20 and 2000 m over NN.
•
Never use the device during thunderstorms. Over
voltage could destroy the device. Always disconnect
the device during thunderstorms.
•
This device must never be operated or stockpiled in
surroundings where splash water, rain, moisture or
fog may harm the device. Moisture or very high
humidity can reduce the insulation and lead to mortal
electrical shocks.
•
When using smoke machines, make sure that the
device is never exposed to the direct smoke jet and is
installed in a distance of 0.5 meters between smoke
machine and device.
Serial Barcode
•
Never remove the serial barcode from the device as
this would make the guarantee void.
Transport
•
Please use the original packaging if the device is to
be transported.
www.eurolite.de
International
L
N
Modifications and Guarantee
•
Please consider that unauthorized modifications on
the speaker system are forbidden due to safety
reasons!
•
If this device will be operated in any way different to
the one described in this manual, the product may
suffer damages and the guarantee becomes void.
Furthermore, any other operation may lead to
dangers like short-circuit, burns, electric shock, etc.
WEEE Directive
If the units are to be put out of operation
definitively, take them to a local recycling plant
for a disposal which is not harmful to the
environment. Do not dispose of as municipal
waste. Contact your retailer or local authorities
for more information.
