Product Overview
Overview of all Features
●
DMX controller for DMX light effect units such as moving heads, scanners and LED spot lights with RGBW color
mixture
●
512 DMX channels can be assigned and inverted as desired to 34 control channels (softpatch)
●
For 24 fixtures with max. 34 control channels each
●
USB port for storing program data
●
Quick programming thanks to 9 integrated movement patterns and 6 color effects (pan/tilt position, fade time and
running time adjustable)
●
Several movement patterns and color effects can be used simultaneously
●
30 programmable chases with 100 scenes each can be stored
●
Manual, time-controlled or sound-controlled chase running mode
●
30 programmable scenes
●
4 DMX fixture levels can be controlled
●
8 motorized DMX channel faders for user-friendly control
●
The motor faders provide a precise overview of the parameters when switching the individual banks, chases and
scenes
●
2 jog wheels for pan/tilt
●
Master fader for color and dimmer channels
●
Blackout function
●
Color-illuminated buttons provide easy orientation
●
Sound control via built-in microphone
●
Backlit LCD (2 x 16 characters)
●
RDM support (DMX address setup and identify)
●
3-pin XLR connector
●
Firmware update via USB
●
Rack installation with 3 units
●
Use as desktop console possible
