(6) Turn the knob, select <SENDING CARD NO.>, push the knob to confirm. Turn the knob and select "No.1",
push the knob to confirm. Shown as follows:
(7) After setting, turn the rotary knob, select <QUICK CONNECTION>, push the knob to confirm for next setting,
shown as follows:
(8) Turn the knob, select <RECEIVING CARD SET>, push the knob to confirm. Turn the knob again, and select
<CHOOSE CABLE>, push the knob to confirm. Turn the knob, select PORT U1 and push the knob to confirm.
(9) Set the horizontal card, vertical card, width and height. For example, set horizontal card as 3, vertical card as
2, width and height as 120, shown as follows:
Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
SENDING CARD TYPE
->SENDING CARD NO.
OUTPUT FORMAT
QUICK CONNECTION
SENDING CARD TYPE
SENDING CARD NO.
OUTPUT FORMAT
->QUICK CONNECTION
->SENDING CARD SET
RECEIVING CARD SET
SENDING CARD SET
->RECEIVING CARD SET
->CHOOSE CABLE
HORIZONTAL CARD
VERTICAL CARD
WIDTH
CHOOSE CABLE
->HORIZONTAL CARD
VERTICAL CARD
WIDTH
LINSN
No.1
>>
>>
LINSN
No.1
>>
>>
>>
>>
>>
>>
PORT U
1
1
64
PORT U
3
2
120
9
