Write; The Flash Tab - Altera Cyclone IV GX User Manual

Chapter 6: Board Test System
Using the Board Test System

Write

The Write control writes the SSRAM on your board. To update the SSRAM contents,
change values in the table and click Write. The application writes the new values to
SSRAM and then reads the values back to guarantee that the graphical display
accurately reflects the memory contents.

The Flash Tab

The Flash tab allows you to read and write flash memory on your board.
shows the Flash tab.
Figure 6–5. The Flash Tab
The following sections describe the controls on the Flash tab.
© March 2010 Altera Corporation
Figure 6–5
Cyclone IV GX Transceiver Starter Kit User Guide
6–9
