Chapter 6: Board Test System
Using the Board Test System
■ Name—Indicates the official name of the board, given by the Board Test System.
■ Part number—Indicates the part number of the board.
Serial number—Indicates the serial number of the board.
■
■ Factory test version—Indicates the version of the Board Test System currently
running on the board.
■ Factory test date—Indicates the release date of the Board Test System currently
running on the board.
■ MAX II version—Indicates the version of MAX II code currently running on the
board. The MAX II code resides in the <install
dir>\kits\cycloneIVGX_4cgx15_starter\examples directory. Newer revisions of
this code might be available on the
the Altera website.
■ MAC address—Indicates the MAC address of the board.

MAX II Registers

The MAX II registers control allow you to view and change the current MAX II
register values as described in
take effect immediately. For example, writing a 0 to SRST resets the board.
Table 6–2. MAX II Registers
Register Name
System Reset
(SRST)
Page Select Register
(PSR)
Page Select Override
(PSO)
Page Select Switch
(PSS)
© March 2010 Altera Corporation
Cyclone IV GX Transceiver Starter Kit
Table 6–2. Changes to the register values with the GUI
Read/Write
Capability
Write only Set to 0 to initiate an FPGA reconfiguration.
Read / Write Determines which of the pages of flash memory to use for
FPGA reconfiguration. The flash memory ships with pages 0
and 1 preconfigured.
Read / Write When set to 0, the value in PSR determines the page of
flash memory to use for FPGA reconfiguration. When set to
1, the value in PSS determines the page of flash memory to
use for FPGA reconfiguration.
Read only Holds the current value of the iluminated PGM LEDs (D3-
D4) based on the following encoding:
0 = PGM 0 LED (D4) on and PGM 1 LED (D3) on, and
■
corresponds to the flash memory page for the factory
hardware design
1 = PGM 0 LED (D4) on and PGM 1 LED (D3) off, and
■
corresponds to the flash memory page for the user
hardware 1 design
2 = PGM 0 LED (D4) off and PGM 1 LED (D3) on, and
■
corresponds to the flash memory page for the user
hardware 2 design
Description
Cyclone IV GX Transceiver Starter Kit User Guide
6–5
page of
