28 | Unit Configuration

UNIT CONFIGURATION

Bosch EasyStart App

The Bosch EasyStart app is a digital interface that
allows access to information from the Heat Pump
Controller (HPC) making commissioning,
configuring, and troubleshooting easier. This
application is available in the Google Playstore, the
Apple App Store, as well as the Bosch Pro HVAC
website (www.boschprohvac.com). Search for
"Bosch EasyStart" in the appropriate store for your
device to download and launch the app. Once
launched, navigate through the legal information,
and then the user guide displays, explaining how to
connect the App and the heat pump, as well as
how to explore the features of the Bosch EasyStart
app.
Freeze Protection Strategy
Cooling CFM per TON
Heating CFM per TON
Fan Only CFM reduction
Dehumidification CFM reduction
Heat Recover Package
Heat Recovery Setpoint
Heat Recovery Sample Rate
Electric Heat Size
Low Loop Water Protection
Low Loop Control Setpoint
Loop Pump Compressor Delay
Mode of Compressor Operation
Down-Staging
Number of Lockouts
Lockout Reset
Units of Temperature
Alarm Type
Date
Time
High Efficiency Mode
Compressor Runtime Reset
Model Number (from the Unit Data Plate)
Serial Number (from the Unit Data Plate)
Table 3 HPC Settings
8733819578 (2019/02)
HPC Settings
15°F–26°F
300–450
300–450
50–100%
15–40%
Enabled or Disabled
110°F–140°F
2–6 Samples/Hr
None, 5kW, 10kW, 15kW, 20kW
Enabled or Disabled
20°F–50°F
30–240 seconds
Comfort or Economy
Latched or Unlatched
2–4 Strikes
(Y1) signal or (R)
°F or °C
Constant or Pulse
MM/DD/YYYY
HH:MM
Enable or Disabled
Write Only
SM036-1VTC-FRTADC-
CMGXXXXXD7HXXX4XXXXSNA
1234-567-891011-1213141516
Subject to change without prior notice
The Bosch EasyStart app will only work on the
following devices: Android tablets with Android 4.0
operating system or higher, Apple iPads with iOS 8
or higher, and Windows 7.0 or higher laptops/PCs.
For more information refer to the website list in
the Bosch EasyStart app's Installation,
Operation, and Maintenance Manual (IOM).

Settings

The Bosch EasyStart app is used to configure the
available features of the HPC as follows:
26°F
400 CFM/Ton
375 CFM/Ton
80%
15%
Disabled
120°F
3 Samples/Hr
None
Disabled
34°F
30s
Comfort
Unlatched
3 Strikes
(Y1)
°F
Pulse
Disabled
Greensource CDi Series SM
Default Settings
Greensource CDi Series SM Model
