Appendix A: Restoring Factory Default Settings

Appendix A: Restoring Factory Default Settings
In the event that the IP address or passwords are forgotten, WebRelay-10 may be restored to its original
factory default settings.
1. Remove the DC power from the unit. This will also de-energize any relay coils.
2. Use a thin, non-conductive object (such as a toothpick) to press and hold the small
button located next to the RJ-45 connector. A tactile feel can be detected as the button is pressed.
CAUTION: DO NOT USE METAL OBJECTS FOR THIS FUNCTION.
3. While depressing the button, apply power and wait for about 10 seconds before releasing the button.
All settings will be back to the original factory defaults. log.txt and syslog.txt are retained.
4. Refer to Section 2.3 Establishing Communications for Setup to begin reconfiguration of the
device.
Figure Appendix A.1 - Restore Factory Defaults
