Installation and Setup
2.4.6 Logging Tab (WebRelay-10 Plus™ only)
WebRelay-10 Plus™ can be configured to record data such as changes in relay and input state, sensor
data, and events. Both periodic and event-based logging are supported. The logged data is stored in
internal nonvolatile memory and can be retrieved by entering the command http://{WebRelay-10 IP
address}/log.txt. For more information on logging, see Appendix D: Log Files.
Note: Changing the log settings will erase the current log file.
Figure 2.4g - Logging Tab
Logging Enabled
When this option is set to Yes, WebRelay-10 Plus™ will record data as configured on this page. The
default setting for this option is No.
Note: This option controls data logging, but not system logging. System logging is always enabled.
Start Time
If a logging interval is specified (periodic logging rather than event logging), logging will occur
relative to this start time. For example, if the start time is 01:00 and the logging rate is 6 hours,
logging will occur at 01:00, 07:00, 13:00, and 19:00. Start time is specified in 24-hour time format.
