Installation and Setup
Configuration of events is accomplished by clicking on the appropriate event, which causes the following
setup screen to be displayed.
Figure 2.4m - Event Setup
Current Date/Time
This field displays the current date and time as specified in the Date/Time tab.
Schedule #
WebRelay-10 Plus™ can be setup to use multiple schedules. The master event schedule is
schedule 0. (See Schedules at the end of this section for more information.)
Description
Text entered here is used to name and describe each event. The default text is Event
Description.
Start Date
This field is used to enter the start date of the event. The date is entered by first selecting the correct
month and year by using the left and right arrows at the top of the calender. The single arrows (<
and >) change the month and the double arrows (<< and >>) change the year. Once the current
month and year are displayed, the date should be entered by selecting the day.
Start Time (HH:MM:SS)
The start time of the event is entered in the drop down menus as HH:MM:SS (HH represents hours
in 24-hour format [00-23], MM represents minutes [00-59], SS represents seconds [00-59]). Default
setting is 00:00:00.
Period
When events are configured to occur more than one time (any entry other than 1 in the Count
below), the period field specifies the time between the beginning of events. This time can be
specified in Seconds, Minutes, Hours, Days, or Weeks by selecting the appropriate option in the
drop down menu. Default settings is 0 Days. Note that selecting 0 will disable the event.
Days
When a Period of one day is selected, the day (or days) on which that event will occur can be
