2.1 Mounting
WebRelay-10 can be mounted to a standard (35mm by 7.55mm) DIN-Rail. Attach the module to the
DIN-Rail by placing the top hooks on the back of WebRelay-10 to the DIN-Rail and then snapping the
bottom hooks into place. Remove from the DIN-Rail by depressing the latch-release on the mounting
bracket.
See Appendix L: Mechanical Information for additional mechanical details.
page 10
Figure 2.1a - DIN-Rail Mount
