Installation and Setup
4. In the Local Area Connection Properties window in
the Connection Uses box, scroll down and
highlight "Internet Protocol (TCP/IP)." Click the
button labeled "Properties." The "Internet Protocol
(TCP/IP)" Properties menu appears (Figure 2.3e).
5. Select the radio button labeled "Use the following
IP address" and type in the IP address:
192.168.1.50
6. Type in the subnet mask:
255.255.255.0
No need to change the default gateway field. Click
OK to accept the new settings.
Note: If "Use the following IP address" is already
selected, the computer has been set up with a
static IP address. Record these values so that the
computer can be restored once the IP address of
WebRelay-10 is successfully changed.
7. Open the setup pages as described in section 2.4.
If the setup pages are not accessible, verify that
WebRelay-10 is powered on and that the LINK
light is illuminated. Check all network connections and settings.
Another way to check communications is to ping WebRelay-10 (from the command prompt by typing
ping {WebRelay-10 IP address} ).
page 20
WebRelay-10 Users Manual
Figure 2.3e- TCP/IP Properties
