Installation and Setup
2.4.7 Inputs Tab (WebRelay-10 Plus™ only)
This page provides configuration options for the two control inputs built into WebRelay-10 Plus™.
Figure 2.4h - Inputs Tab
Note: In this manual, the input is considered to be ON when the input is tied to ground.
Input
This drop down menu is used to select the control input to which the options below will apply.
- Input 1 or Input 2: Selects the corresponding control input.
Description
This text field is used to describe the function of the selected input. The text appears to the left of the
corresponding input status on the Control Page, and in email messages when email alerts are
enabled. This field may be up to 24 characters long. The default text is Input #.
On Status Text
The text in this field specifies the text that will be displayed in the Control Page and in email
messages when the input is ON (input tied to ground). Up to 14 characters may be entered in this
field. The default text is ON.
Off Status Text
The text in this field specifies the text that will be displayed in the control page and in email
messages when the input is OFF (input is open). Up to 145 characters may be entered in this field.
The default text is OFF.
Counter Options
The inputs can be used as counters. This field specifies counter operation.
