THE HARNESS
7
1
8
QUICK RELEASE HOOK
Easily attach and release the machine from
After use of the quick release hook it will
the harness using the quick release hook.
need to be re-assembled.
To release the unit from the hook pull the
Place the lower hook over the upper hook
orange tab.upwards.
with orange tab attached.
Please make sure the machine is properly
secured or supported before releasing the
quick release hook to prevent damage.
NOTE: Ensure engine is turned off before using the quick release hook
i
WARNING! Before using quick release hook place machine on a solid surface, dropping the machine will cause damage to the unit.
46
9
REPLACE LOWER HOOK
INSERT RELEASE PIN
Place the release pin through the slot in the
upper hook making sure that the pin passes
over the lower hook.
The quick release hook is now re-assembled
and ready to be used again when needed.
