FITTING THE CHAIN, BAR & TENSIONING CHAIN
6
1
7
ADJUST CHAIN TENSION
When correctly adjusted it should be
Turn the chain tension adjustment screw
clockwise until the chain pulls tight on the
possible manually run the chain around the
bottom of the bar.
bar and pull one complete chain link clear
of the groove.
NOTE: Inspect and adjust the chain regularly until the initial stretch has been taken out.
WARNING! Take care when handling the chain as it is sharp. Use appropriate safety gloves to prevent injury.
NOTE: When the chain begins to wear, the cutting performance will reduce. Sharpen or replace it with an identical one.
38
8
CHECK CHAIN TENSION
SECURE SPROCKET COVER
Once satisfied with the chain tension
tighten the 10mm nut securely using the
spanner provided within the tool kit.
1
CHAINSAW GREASE NIPPLES
The components within the gearbox have to work
very hard and as a result MUST remain well
lubricated at all times. Before or after each use.
WARNING! Use an appropriate gearbox grease. Failure to do so can result in unit failure.
i
NOTE: Always keep gearbox lubricated either before or after use. Lack of lubrication can cause unit failure
CHAINSAW GEARBOX LUBRICATION
2
ADD GREASE TO CHAINSAW
Connect a compatible grease gun to the chainsaw
gearbox assembly's grease nipple.
Pump gearbox grease into the grease nipple.
Use a general purpose gearbox grease.
39
