THE HARNESS

1 1 2
THE HARNESS
Place the Harness over your head ensuring
Included with your PGMT-5200 is the
harness. The harness ensures you can work that the padded shoulder straps are placed
both safely and comfortably whilst using on to your shoulders
your machine.
It features padded straps for extra comfort,
protective thigh pad, fully adjutable straps
and a quick release hook.
CAUTION: For your own safety, comfort and for best results always use the PGMT-5200 with the harness provided
44
3
PLACE OVER HEAD SNAP BUCKLE
Lock the snap buckle to secure the harness
loosely in place
4 5
1
ADJUST TO FIT
The harness is fully adjustable with 8 strap Ensure the thigh pad is located in the correct
adjusters to ensure the best possible fit. Be position so it protects you fully from pres-
sure points created from contact with the
sure to evenly spread the weight over both
shoulders using the strap adjusters. machine during use.
The thigh pad is normally positioned on the
Tighten or loosen the harness to best suit
your frame. Please be aware you may need right hand side, this is the same side that the
to re-adjust to ensure the harness is in the machine will be positioned.
most comfortable position to suit you.
THE HARNESS
6
THIGH PAD FRONT VIEW & REAR VIEW
Your harness is designed to be worn with
the snap buckle at the front.
The Multi Tool should hang on the right and
rest against the thigh pad.
The back plate should sit centrally on your
back. Adjust the harness so it is secured
against your body in the most comfortable
position.
The harness is easily adjusted by utilizing
the strap adjusters.
