Silicon Laboratories Z-WAVE 700 Integration Manual page 5

Instruction: Z-Wave 700 Integration Guide
regions are defined to cover the global Z-Wave frequency range. The SAW filter specifications described in Table 6.1, Table 6.2,
and Table 6.3 are recommended for new designs.
Operating temperature
Insertion loss
Amplitude ripple
Relative attenuation
In / out impedance
Operating temperature
Insertion loss
Amplitude ripple
Relative attenuation
In / out impedance
Operating temperature
Insertion loss
Amplitude ripple
Relative attenuation
In / out impedance
INS14487-3 | 2/2019
Table 6.1: Region E
Frequency Range
-
865.0 to 870.1MHz
865.0 to 870.1MHz
0.1 to 800.0MHz
805 to 830MHz
835 to 855MHz
860 to 862MHz
890 to 1000MHz
1005 to 2000MHz
2005 to 3000MHz
3005 to 4000MHz
4005 to 6000MHz
-
Table 6.2: Region U
Frequency Range
-
908.2 to 916.3MHz
908.2 to 916.3MHz
720 to 800MHz
805 to 840MHz
845 to 870MHz
870 to 895MHz
940 to 1000MHz
1005 to 2000MHz
2005 to 3000MHz
3005 to 4000MHz
4005 to 6000MHz
-
Table 6.3: Region H
Frequency Range
-
919.5 to 926.5MHz
919.5 to 926.5MHz
40 to 870MHz
875 to 885MHz
890 to 905MHz
945 to 955MHz
960 to 1000MHz
1005 to 1500MHz
1505 to 3000MHz
3005 to 4000MHz
4005 to 6000MHz
-
Unit Minimum
C -30
◦
dB -
dB -
dB 40
dB 35
dB -
dB -
dB 40
dB 30
dB 30
dB 30
dB -
-
Ω
Unit Minimum
C -30
◦
dB -
dB -
dB 45
dB -
dB 40
dB -
dB 9
dB 9
dB 17
dB -
dB -
-
Ω
Unit Minimum
C -30
◦
dB -
dB -
dB 40
dB 35
dB 20
dB 20
dB 20
dB 40
dB 20
dB -
dB -
-
Ω
Typical Maximum
- +85
- 3.5
- 2.0
- -
- -
- -
- -
- -
- -
- -
- -
- -
50 -
Typical Maximum
- +85
- 2.5
- 1.5
- -
- -
- -
- -
- -
- -
- -
- -
- -
50 -
Typical Maximum
- +85
- 3.2
- 1.0
- -
- -
- -
- -
- -
- -
- -
- -
- -
50 -
5
