PROCESS AUTOMATION
MANUAL
VisuNet GXP
RM-GXP1100 and
RM-GXP1200
System Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VisuNet GXP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pepperl+Fuchs VisuNet GXP Series

  • Page 1 PROCESS AUTOMATION MANUAL VisuNet GXP RM-GXP1100 and RM-GXP1200 System Manual...
  • Page 2 VisuNet GXP RM-GXP1100 and RM-GXP1200 With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
  • Page 3: Table Of Contents

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Introduction................. 4 Content of this Document ..............4 Target Group, Personnel..............4 Symbols Used ..................4 Product Description ..............6 Overview ....................6 Technical Specifications..............8 Dimensions..................10 Scope of Delivery................10 Mechanical Installation ............11 Unpacking...................
  • Page 4: Introduction

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Introduction Introduction Content of this Document This document contains information that you need in order to use your product throughout the applicable stages of the product life cycle. These can include the following: Product identification Delivery, transport, and storage Mounting and installation Commissioning and operation...
  • Page 5: Symbols Used

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid property damage.
  • Page 6: Product Description

    The thin client units TCU1100-* and TCU1200-* are computing units running the latest Pepperl+Fuchs RM shell 4.x firmware. They allow connecting to various sets of host systems in the safe are, using standard Ethernet technology.
  • Page 7: Technical Specifications

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Product Description Technical Specifications Technical Data Hardware Processor Intel® Atom™ Bay Trail E3827 1.75 GHz 2 GB DDR3L Mass storage 32 GByte industrial grade MLC SSD Supply Power consumption max. 72 W , typ. 55 W Interface Interface type 1 x Ethernet 100/1000BASE-T 1000 MBit/s (Ex e) or fiber optic...
  • Page 8 VisuNet GXP RM-GXP1100 and RM-GXP1200 Product Description Mechanical specifications Mass Panel (DPU with bezel, TCU, PSU DC): approx. 17.5 kg Panel (DPU with bezel, TCU, PSU AC): approx. 18 kg System housing: approx. 11 kg Dimensions Panel (DPU with bezel, TCU, PSU DC): 625x459x120 mm Panel (DPU with bezel, TCU, PSU AC): 625x459x137 mm Panel with system housing: 625x459x173 mm Note!
  • Page 9: Dimensions

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Product Description Dimensions Dimensions ~ 400 Scope of Delivery 1x Pre-assembled VisuNet RM-GXP Panel (Option: Panel mounted into AG-XX00 housing) 2x Protective tubes Screws for housing...
  • Page 10: Mechanical Installation

    NEVER use a display unit with a scratched front screen in a hazardous area. If the surface is damaged in any way, return the display unit to Pepperl+Fuchs at once and replace it with a new one. To this end, remove the display unit. See chapter 3.2.7...
  • Page 11 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation...
  • Page 12: System Installation

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation System Installation 3.2.1 Preparing the Pedestal For floor mounting, the preferred installation option is using PEDESTAL-XX00-*. This is shipped with a pre-installed rotating coupling with four headless screws and a grounding cable which is fixed to the pedestal tube.
  • Page 13: Mounting The Housing

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.2 Mounting the Housing Warning! Risk of injuries Lifting the device on your own may lead to injury. Do not attempt to lift the device on your own. Use a crane or get another person to help you. Warning! Risk of injuries While the device is resting on the pedestal and the nuts have not yet been fixed to the screws,...
  • Page 14 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 1. While manually securing the housing (e.g. by holding on to it), remove all screws from its back. 2. While manually securing the housing (e.g. by holding on to it), slowly pull on both lower corners of the display bezel until the display slides out of the housing completely.
  • Page 15 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation While manually securing the housing (e.g. by holding on to it), tip the display panel towards you until the display comes to rest in its fully openend position, hanging down at an angle from its tightened strings.
  • Page 16: Closing The Housing

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.3 Closing the Housing Warning! Risk of finger injury Fingers can become squeezed in and stuck when the display is moved backed into the housing. Wear protective gloves, hold the display panel by the frame when moving it and mind your fingers.
  • Page 17 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 5. Fasten the the two screws with a torque of 6 Nm. 6. Repeat the last step with all other screws following a diagonal pattern.
  • Page 18: Mounting The Keyboard

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.4 Mounting the Keyboard The TASTEX EXTA 2 keyboard is the system keyboard available with a mounting option for the VisuNet GXP housing AG-XX00. Mounting the EXTA2-*-G-* Keyboard to Housing AG-XX00 1. Open and remove the four cover plate screws on the left side of the AG-XX00 housing bot- tom.
  • Page 19: Mounting The Scanner Holder To The Housing

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.5 Mounting the Scanner Holder to the Housing The SCANNER-HOLDER-PSCAN-XX00-N0 (#548121) is a scanner holder for the PSCAN-* scanner family that is compatible with the VisuNet GXP housing AG-XX00. We recommend using the following tools for the installation: Split socket pliers Gloves Hex key drivers (2.5 mm and 3 mm)
  • Page 20 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 5. Press the scanner holder against the housing from the outside and fasten the screw using a torque of 6 Nm. 6. Use the hex key to put the second screw (with lock washer and sealing washer) through the drilled hole at the right side of the AG-XX00 housing and fasten the screw using a torque of 6 Nm.
  • Page 21: Installing The Scanner Cable

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.6 Installing the Scanner Cable The DATL-PSCAN-D-XX00-N0 (#548133) is a cable for the installation of the PSCAN-D barcode reader to the VIsuNet GXP RM/PC. The scanner cable is compatible with the VIsuNet GXP housing AG-XX00 and allows to install the scanner interface plug into the housing. Installing Scanner Cable DATL-PSCAN-D-XX00-N0 1.
  • Page 22: Dismounting The Display Unit

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3.2.7 Dismounting the Display Unit Note! For repair purposes, the display unit can be dismounted from the computing unit (TCU or PCU) and be replaced individually. Warning! Danger of Explosion An ignition may be triggered if the computing unit is still energized when its compartment room is opened.
  • Page 23 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 3. Remove the grounding cable from the grounding bolt at the back of the display unit. 4. Now the display unit can be removed from the enclosure completely. During the removal process, make sure to hold the display unit steady so it cannot fall down, preferably with the help of another person, and to place it on an upholstered and even surface after removal.
  • Page 24 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 5. Remove the two brackets (1) as well as the 10 bolts at the top, sides, and bottom of the display unit (2). Then, remove the carabiners (3) from their brackets, take out the six bracket screws (4), and remove the carabiner brackets.
  • Page 25: Panel Mount Installation

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation Panel Mount Installation If the Panel Mount Option is chosen, you will receive a pre-assembled package consisiting of a display unit, a computing unit, and a power supply unit. The following kit for panel mounting can be ordered separately: 2x L-shaped panel mount brackets (1 left, 1 right) 1 rectangular stiffener frame 14x M5x25 socket head cap screw (torque: 1.8 Nm)
  • Page 26 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 2. From the front, place the panel in the cabinet cutout hole (1) and move it to an upright vertical position (2). 3. From inside the cabinet, add the stiffener frame, position it (1)-(3), and press it against the back of the cabinet wall.
  • Page 27 VisuNet GXP RM-GXP1100 and RM-GXP1200 Mechanical Installation 4. Prepare the other L-shaped bracket with the mounting screws. 5. Mount the prepared L-shaped bracket to the display unit housing (1), then affix both L- shaped brackets with all screws to the stiffener frame (2). 6.
  • Page 28: Electrical Installation

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Electrical Installation Electrical Installation Warning! Danger of Explosion Disconnecting cables too quickly may trigger an ignition, as device-internal cable capacitances need some time to discharge. After de-energizing, wait 3 minutes before opening the compartment room or disconneting the device from the display unit.
  • Page 29: Grounding The Housing To The Pedestal

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Electrical Installation Grounding the Housing to the Pedestal Grounding the AG-XX00 Housing to PEDESTAL-XX00-*. 1. Connect the pre-installed PE wire of the pedestal to the grounding bolt of the AG-XX00 hous- ing. 2. Ground the pedestal with the grounding stud on the bottom plate of PEDESTAL-XX00-*. 3.
  • Page 30: Grounding The Housing To The Wall-Bracket

    VisuNet GXP RM-GXP1100 and RM-GXP1200 Electrical Installation Grounding the Housing to the Wall-Bracket Grounding the AG-XX00 Housing to WALL-BRACKET-XX00-* 1. Ground the wall bracket with the grounding bolt on the bottom of the WALL-BRACKET- XX00-*. 2. Fasten the screw with a torque of 6 Nm. Note! The AG-XX00 housing is grounded indirectly via the wall bracket.
  • Page 31: Appendix

    Item Number Name Description #548121 SCANNER-HOLDER-PSCAN-XX00-N0 Scanner holder for PSCAN- D/PSCAN-M barcode reader Compatible with AG-XX00-* housing #548133 DATL-PSCAN-D-XX00-N0 Connector cable for PSCAN-D barcode reader Compatible with AG-XX00-* housing Note! For more options and accessories, please contact your local Pepperl+Fuchs sales representative.
  • Page 32 PROTECTING YOUR PROCESS Worldwide Headquarters Pepperl+Fuchs GmbH 68307 Mannheim · Germany Tel. +49 621 776-0 E-mail: info@de.pepperl-fuchs.com For the Pepperl+Fuchs representative closest to you check www.pepperl-fuchs.com/contact www.pepperl-fuchs.com Subject to modifications 302041 / DOCT-5482 Copyright PEPPERL+FUCHS • Printed in Germany 05/2017...
