- Page 1 PROCESS AUTOMATION MANUAL VisuNet Display Unit DPU2100-*...
- Page 2 VisuNet Display Unit With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
-
Page 3: Table Of Contents
VisuNet Display Unit Introduction................. 4 Content of this Document ..............4 Target Group, Personnel..............4 Symbols Used ..................5 Product Description ..............6 Overview ....................6 Technical Data ..................7 Marking ....................9 Dimensions and Type Labels.............. 9 Installation................. 11 Special Conditions of Use.............. -
Page 4: Introduction
VisuNet Display Unit Introduction Introduction Content of this Document This document contains information that you need in order to use your product throughout the applicable stages of the product life cycle. These can include the following: Product identification ■ Delivery, transport, and storage ■... -
Page 5: Symbols Used
VisuNet Display Unit Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid property damage. -
Page 6: Product Description
The DPU2100-* display unit is an ATEX/IECEx certified device intended for use in potentially explosive atmospheres such as Zones 1/21. Connected to a Pepperl+Fuchs thin client unit or PC unit, the DPU serves as a display with an optional touchscreen. It enables users to perceive the system outputs of the computing unit and input user data. -
Page 7: Technical Data
5 capacitive front keys (behind glass): 1 home button, 2 brightness control buttons, 1 touchscreen button, 1 power button Interface Interface type interface v1.0 from Pepperl+Fuchs for computing units from Pepperl+Fuchs Directive conformity Electromagnetic compatibility Directive 2014/30/EU EN 61326-1:2013 (industrial locations) ; EN... - Page 8 VisuNet Display Unit Product Description Degree of protection IP66 Material Surface front: glass with powder-coated aluminum (6061) bezel back: powder-coated aluminum Mass approx. 14.5 kg Dimensions 542 mm x 460 mm x 48 mm Data for application in connection with hazardous areas EU-Type Examination Certificate CML 17 ATEX 5191X Marking...
-
Page 9: Marking
Product Description Marking ATEX/IECEx Marking Display Unit DPU2100-* Pepperl+Fuchs GmbH Lilienthalstraße 200, 68307 Mannheim, Germany ATEX: CML 17 ATEX 5191X II 2G Ex eb ib q IIC T4 Gb II 2D Ex tb IIIC T85 °C Db IECEx: IECEx CML 17.0106X Ex eb ib q IIC T4 Gb Ex tb IIIC T85 °C Db... - Page 10 VisuNet Display Unit Product Description Labels The following labels are present on the display unit. Type label display unit Warning marking "Warning – Do not open! This enclosure is factory sealed." Warning - Do not open! "Avertissement – Cette enveloppe est scellée This enclosure is factory en usine.
-
Page 11: Installation
The device shall be installed such that risk of high-impact energy on display glass is ■ considered to be low. The unit type DPU2100-* may only be used in connection with Pepperl+Fuchs computer ■ unit *CU1100-J1-* according to EU-Type examination certificate BVS 16 ATEX E 083X for ATEX applications or IECEx BVS 16.0060X for IECEx applications. -
Page 12: Mechanical Installation
Mounting the PCU/TCU onto the DPU 1. Ensure the correct position of the PCU/TCU. 2. Place the PCU/TCU with the Pepperl+Fuchs connector above the Pepperl+Fuchs socket on the back of the display unit. 3. Carefully push the Pepperl+Fuchs connector into the Pepperl+Fuchs socket. -
Page 13: Repair And Disposal
Repair and Disposal Note! The DPU can be dismounted from the PCU/TCU and sent to Pepperl+Fuchs for repair and/or replacement. For mounting and dismounting instructions, see Chapter 3.3. The powder filling (Ex q) of the display is not user-serviceable. Send the device to the factory for repairs, if required. -
Page 14: Operation And Configuration
VisuNet Display Unit Operation and Configuration Operation and Configuration Front Buttons The DPU2100* provides several system functions via the capacitive front buttons. The front buttons are embedded in the system and located behind the security glass. Warning! Warning! Do not use sharp tools like screw drivers to trigger the front buttons. Warning! Warning! Do not use the display when there are scratches in the front glass. - Page 15 VisuNet Display Unit Operation and Configuration Status OFF - Power OFF Status OFF - on (solid Power ON white) Power ON - on (solid on (solid on (solid on (solid on (solid Touchscreen white) white) white) white) green) Power ON - on (solid on (solid on (solid...
- Page 16 VisuNet Display Unit Operation and Configuration Power ON - Touchscreen ON Power LED solid green ■ Other LEDs solid white ■ Power ON - Touchscreen OFF Power LED solid green ■ Touchscreen LED flashing white ■ Other LEDs solid white ■...
- Page 17 VisuNet Display Unit Operation and Configuration Sleeping Power LED flashing green ■ Other LEDs off ■ Brightness Control The Service controller sets the backlight brightness and controls it directly with the two brightness buttons Increasing/Reducing Brightness 1. To increase the display brightness, press the button.
- Page 18 VisuNet Display Unit Operation and Configuration Touch Sensitivity To increase or decrease the sensitivity of the touchscreen, a number of different sensitivity profiles are available. This allows adjusting the sensitivity of the touch sensor according to the application requirements (e.g. for working with gloves). Increasing/Decreasing Touch Sensitivity by Choosing a Sensitivity Profile To choose a sensitivity profile, use the VisuNet RM Shell user interface.
- Page 19 VisuNet Display Unit Operation and Configuration Locking and Unlocking Front Buttons The capacitive front buttons are sensitive to water and moisture. To avoid "false positive" button triggers in challenging environments, the front buttons can be protected with a lock mechanism in Service Controller firmware versions 1.3.2.198 and higher.
- Page 20 VisuNet Display Unit Operation and Configuration Apply/Revert Changes in VisuNet RM Shell 5 If you changed settings, the "Apply Changes" button turns green to indicate changes to the current settings. 1. To save the changes, click The changes have been saved. 2.
-
Page 21: Appendix
VisuNet Display Unit Appendix Appendix Health Monitoring CPU / Display Error Indication Problem Solution Home button solid white CPU (Most likely Service Replace the CPU Power button solid red Controller) damaged If backlight still turns on: Replace the display unit Display frontkey controller damaged Temperature Error (too Low) - Page 22 VisuNet Display Unit Appendix Communication Error Indication Problem Solution Touchscreen button solid No communication with DPU Replace display unit white devices (e.g. storage device, Power button solid red temperature monitoring,…)
- Page 23 PROCESS AUTOMATION – PROTECTING YOUR PROCESS Worldwide Headquarters Pepperl+Fuchs GmbH 68307 Mannheim · Germany Tel. +49 621 776-0 E-mail: info@de.pepperl-fuchs.com For the Pepperl+Fuchs representative closest to you check www.pepperl-fuchs.com/contact www.pepperl-fuchs.com Subject to modifications / DOCT-6224A Copyright PEPPERL+FUCHS • Printed in Germany 11/2018...
