SPECIFICATIONS

QS200-10
QS200-10PW
Tee Housing
Material
Insert
Housing
Material
Type
Powered by
Unit of
Measure
0.22-33 GPM
Flow Rate
0.83-124.92 L/min
0.1-15 ft/sec
Accuracy
0.04 GPM
Uncertainty
0.018 ft/sec
Max.
Working
Pressure
Operating
Temperature
Storage
Temperature
Field
Calibration
Inlet / Outlet
1 in. Female
Socket
Connections
0.95 lbs.
Weight
(0.43kg)
INSERTS - ALL METER SIZES
Transducer Excitation
Output Frequency
Output Pulse Width
QS200-15
QS200-15PW QS200-20PW
SCH 80 PVC (Polyvinyl chloride)
PPS (Polyphenylene sulfide) / ULTEM® (Polyetherimide)
Ultrasonic Flowmeter
DC power provided by customer controller
7.5V (dc) min to 36V (dc) max
OFF State Current: 200μA (typical)
Controller Dependant
0.55-82 GPM 0.92-138 GPM
2.08-310.41 L/min 3.48-522.39 L/min
0.1-15 ft/sec 0.1-15 ft/sec
+/- 2% of Reading
0.10 GPM
0.018 ft/sec 0.018 ft/sec
150 PSI @ 70°F (10.3 bar @ 60°C)
+32°F to +140°F (0°C to +60°C)
+32°F to +140°F (0°C to +60°C)
1 1/2 in.
2 in. Female
Female
Socket
1.12 lbs.
(0.51kg)
OFF State Current
OFF State V-High
ON State Current
ON State V-Low
QS200-20 QS200-30
QS200-30PW
2.06-309 GPM
7.80-1169.70 L/min
0.1-15 ft/sec
0.17 GPM 0.37 GPM
0.018 ft/sec
No
3 in. Female
Socket Socket
1.39 lbs. 2.52 lbs.
(0.63kg) (1.14kg)
200µA (typical)
Supply Voltage - (OFF State
Current * Supply impedance)
(Supply Voltage / (Supply
impedance + 50Ω))
ON State Current * 50Ω
0 to 100 Hz
4mSec (Approx.)
QS200-40
QS200-40PW
3.58-537 GPM
13.55-2032.78 L/min
0.1-15 ft/sec
0.65 GPM
0.018 ft/sec
4 in. Female
Socket
3.21 lbs.
(1.46kg)
