INSTALLATION

Below is a typical QS200 meter with labeled components. Familiarize
yourself with the meter before installation.
GREEN LED
I.D. PLATE WITH
SERIAL NUMBER
AND FLOW ARROW
SIZE INFO
Figure 2
8
BLACK WIRE
TYPICAL QS200 METER
RED WIRE
INSERT ASSY.
AMBER LED
QUICK RELEASE
PIN
TEE
PAGE 8
