INSTALLATION (CONTINUED)

Wiring Connections

NOTE: Wiring diagram is shown in next section.
1. When using 18 AWG cable, cut off the unused wires so that they are
even with the sheath of the cable.
NOTE: For 18 AWG connections, remember the color of the twisted pair of
wires you use so that you can make an identical connection with the same
wires later.
2. 3M DBR/Y-6 Splice Kit Instructions:
Figure 8a
Figure 8c
Figure 8b
Figure 8d & 8e
11
