Endless Pools FASTLANE Owner's Manual page 6

Fastlane Swim Unit Installation
®
CHOOSING A LOCATION FOR YOUR FASTLANE
Section 2
The Fastlane can fit in virtually any swimming pool. For optimal water flow, we recommend that you allow
D
W
at least 12 feet (3,7m) between the wall on which the Fastlane is installed and the opposing wall in line with
the Swim Unit. The Fastlane has more than 9 square feet (.83m2) of water intake to eliminate any entrap-
ment hazards. The water depth where the Fastlane is installed must be at least 39" (99cm) deep. In addition,
the Fastlane must be installed no closer than 24" (61cm) from any adjacent wall as shown in Figure 2.1,
Minimum Clearance Guidelines.
When choosing a location for your Fastlane, you should also consider the route for the hydraulic hoses
to run back to the Power Unit. The Power Unit needs to sit on a solid, level surface, preferably not on
wet ground, and requires a 30-amp, 220-volt GFCI electric service. For UK and international electrical
requirements, please refer to Section 11. The optional Outdoor Power Unit with Weather Guard may be
located outside, but should not be subject to driving rain. Typically, the Power Unit is located with the other
pool equipment and, if possible, long hydraulic runs should be avoided because of pressure loss. If you
wish to have a run greater than 25' (7,6m), you must transition from 3/8" (9,5mm) hydraulic hoses to 1/2"
(12,7mm) run hoses with the addition of a junction box as reviewed in Section 5.
Fig. 2.1 Minimum Clearance Guide
RECEIVING YOUR FASTLANE
Section 3
The Endless Pools Fastlane is comprised of a minimum of six (6) parcels. Additional parcels may be
D
W shipped as appropriate. All items will be shipped via UPS Ground.
Items shipped UPS
Parcel 1: Fastlane Propulsion Housing Kit
Parcel 2: Fastlane Propulsion Base Kit
Parcel 3: Hydraulic Power Unit (wireless remote controls and antenna kit located inside controller)
Parcel 4: Hydraulic Fluid (5 Gallon container)
Wall Mount Fastlane
Parcel 5: Wall Mount Fastlane Mounting Kit (wall mount bracket and hardware for wall mount kit)
Parcel 6: Accessory Kit for Fastlane (hat sections, propulsion housing lid, hardware kit
Deck Mount Fastlane
Parcel 5: Accessory Kit for Fastlane (hat sections, propulsion housing lid, hardware kit
Optional Equipment
Weather Guard
Swim Pace Display
5
24"
(61cm)
for Fastlane assembly)
for Fastlane assembly)
Bracket Kit for Deck Mount Fastlane (hanging bracket, deck plate, hardware for bracket kit)
Floor Mirror
Wi-Fi Kit (included in the accessory kit if purchased)
MINIMUM 24" (61cm)
