INSTALLATION and OPERATION MANUAL
IMPORTANT:
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program, product
changes may occur. As such Crane Pumps & Systems, Inc. reserves the right to change product
without prior written notification.
PUMPS & SYSTEMS
A Crane Co. Company
420 Third Street/P.O. Box 603
Piqua, Ohio 45356-0603
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
Submersible Sump Pump
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
SERIES:
BP25
1/4 HP, 3450 RPM
SERIES:
BP33
1/3 HP, 1750 RPM
SERIES:
BP50
1/2 HP, 1750 RPM
DISCONTINUED
Parts may
NOT be available
Form No. 101716-Rev. F
Advertisement
Table of Contents
Related Manuals for Barnes BP25 Series
Summary of Contents for Barnes BP25 Series
- Page 1 Manual Index ® BARNES INSTALLATION and OPERATION MANUAL Submersible Sump Pump SERIES: BP25 1/4 HP, 3450 RPM SERIES: BP33 1/3 HP, 1750 RPM SERIES: BP50 1/2 HP, 1750 RPM DISCONTINUED Parts may NOT be available IMPORTANT: Read all instructions in this manual before operating pump.
-
Page 2: Table Of Contents
C. INSTALLATION ........................7 - 8 D. SERVICE AND REPAIR....................... 8 E. WARRANTY REPAIR......................9 TROUBLE SHOOTING ......................10 EXPLODED VIEW, BP25 SERIES & PARTS LIST .............. 11 EXPLODED VIEW, BP33 & BP50 SERIES & PARTS LIST ..........12 RETURNED GOODS POLICY ..................... 13 WARRANTY WARRANTY REGISTRATION Other brand and product names are trademarks or registered trademarks of their respective holders. -
Page 3: Warning And Safety Precautions
CAUTION ! Pumps build up heat and pressure during operation-allow time for pumps to cool BARNES® Pumps, Inc. is not responsible for losses, injury, before handling or servicing. or death resulting from a failure to observe these safety... -
Page 4: Pump Specifications
SECTION: A- PUMP SPECIFICATIONS - BP25 SERIES DISCHARGE: 1-1/2" N.P.T. Female, Vertical. SPEED: 3450 RPM LIQUID TEMPERATURE: 77°F (25°C) Continuous. LOWER BEARING: MOTOR HOUSING: Cast Iron Design: Sleeve PUMP BODY & STRAINER: MOTOR: Design: Oil-Filled. Thermoplastic. Insulation: Class B. IMPELLER: Design:... -
Page 5: Bp33 Series
SECTION: A- PUMP SPECIFICATIONS - BP33 SERIES DISCHARGE: 1-1/2" N.P.T. Female, Vertical. SPEED: 1750 RPM LIQUID TEMPERATURE: 77°F (25°C) Continuous. LOWER BEARING: MOTOR HOUSING: Cast Iron Design: Sleeve PUMP BODY & STRAINER: MOTOR: Design: Oil-Filled. Thermoplastic. Insulation: Class B. IMPELLER: Design: Multi-Vane Vortex SINGLE PHASE: Shaded Pole. -
Page 6: Bp50 Series
SECTION: A- PUMP SPECIFICATIONS - BP50 SERIES DISCHARGE: 1-1/2" N.P.T. Female, Vertical. SPEED: 1750 RPM LIQUID TEMPERATURE: 77°F (25°C) Continuous. LOWER BEARING: MOTOR HOUSING: Cast Iron Design: Sleeve PUMP BODY & STRAINER: MOTOR: Design: Oil-Filled. Thermoplastic. Insulation: Class B. IMPELLER: Design: Multi-Vane Vortex SINGLE PHASE: Shaded Pole. -
Page 7: General Information
B-4) SERVICE CENTERS: For the location of the nearest Barnes Pumps Service Center, check your catalog, your Barnes Pumps, Inc. representative or Barnes Pumps, Inc. Service Department in Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps &... -
Page 8: Service And Repair
General Comments: SECTION D: SERVICE AND REPAIR 1) Never work in the sump with the power on. WARNING ! - Electrical power to the pump 2) Level controls are factory set. Be certain that the level motor must be disconnected and locked out to control cannot hang up or foul in it’s swing. -
Page 9: Warranty Repair
MODEL VOLT NEMA FULL CORD CORD CORD 60HZ (Nom) START LOAD LENGTH SIZE TYPE CODE AMPS BP25 3450 10Ft. (3M) 16/3 BP25A 3450 10Ft. (3M) 16/3 BP25VF 3450 10Ft. (3M) 16/3 BP25X 3450 20Ft. (6M) 16/3 BP25AX 3450 20Ft. (6M) 16/3 BP25VFX 3450... -
Page 10: Troubleshooting
TROUBLESHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH "CAUSE"... -
Page 11: Exploded View, Bp25 Series & Parts List
BP25 Series PARTS LIST ITEM QTY. PART No. DESCRIPTION Washer Screw Gland Nut Volute Base 102521 Power Cable, 10ft. Screws with 115 volt Plug Volute, Lower 102138 Power Cable, 20ft. 102141 Impeller with 115 volt Plug Shaft Seal 102139 Vertical Float switch... -
Page 12: Exploded View, Bp33 & Bp50 Series & Parts List
BP33 & BP50 Series PARTS LIST ITEM QTY. PART No. DESCRIPTION Terminal Block Screw Cord Grommet Volute Base Washer Screws Gland Nut Volute, Lower 102521 Power Cable, 10ft. 102142 Impeller, BP33 with 115 volt Plug 102143 Impeller, BP50 102138 Power Cable, 20ft. Screws with 115 volt Plug Volute, Upper... -
Page 13: Returned Goods Policy
IMPORTANT ! WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps &... -
Page 14: A Crane Co. Company 420 Third Street/P.o. Box
BARNES ® Limited Warranty We warrant to our immediate customer and to the ultimate consumer that products of our manufacture will be free of defects in material and workmanship under normal use and service for the following time periods, when installed and maintained in accordance with our instructions. -
Page 15: Warranty Registration
IMPORTANT ! WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps &... - Page 16 FOLD HERE AND TAPE, DO NOT STAPLE PLACE STAMP HERE CRANE PUMPS & SYSTEMS, INC. WARRANTY SERVICE GROUP 420 THIRD STREET P.O. BOX 603 PIQUA, OHIO 45356-0603 - U.S.A.
