INSTALLATION and OPERATION MANUAL
Submersible Sewage Ejector
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
BARNES
Series: 3SE-DS, 3HP
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
1750RPM, 60Hz.
(Double Seal)
Form No. 133408-Rev. E
Advertisement
Table of Contents
Related Manuals for Barnes 3SE3054DS
Summary of Contents for Barnes 3SE3054DS
- Page 1 Manual Index BARNES BARNES ® INSTALLATION and OPERATION MANUAL Submersible Sewage Ejector Series: 3SE-DS, 3HP 1750RPM, 60Hz. (Double Seal) IMPORTANT! Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur.
-
Page 2: Table Of Contents
PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1996, 1997, 1998, 1999, 2001, 2002, 3/06, 9/06, 2/07... -
Page 3: Safety First
SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This information is provided for SAFETY and to PREVENT Do not block or restrict discharge hose, as discharge EQUIPMENT PROBLEMS. To help recognize this information, hose may whip under pressure. observe the following symbols: IMPORTANT! Warns about hazards that can result WARNING! - DO NOT wear loose clothing that may... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: 1750RPM DISCHARGE ....3” NPT, Vertical UPPER BEARING: LIQUID TEMPERATURE . 104°F (40°C) Continuous Design ..Single Row, Ball, Oil Lubricated MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 Load ..... Radial VOLUTE ......Cast Iron ASTM, Class 30 LOWER BEARING: SEAL PLATE .... -
Page 5: General Information
SECTION B: GENERAL INFORMATION C-1.1) Submergence: It is recommended that the pump be operated in the submerged condition and the sump liquid level should never B-1) To the Purchaser: be less than dimension “A” in Figure 1. Congratulations! You are the owner of one of the fi nest pumps on the market today. -
Page 6: Electrical Data
.68 (17.4) 1.40 3SE3044DS 460/3 1750 28.0 14/4 SOOW/SOW .57 (14.5) 6.30 3SE3054DS 575/3 1750 23.0 14/4 SOOW/SOW .57 (14.5) 9.90 Winding Resistance ± 5%. Pump rated for operation at ± 10% voltage at motor. Moisture & Temperature sensor cord for all models is 18/5 SOOW/SOW, 0.47” (11.9mm) O.D. -
Page 7: Start-Up Operation
SECTION: D START-UP OPERATION SECTION F: SERVICE AND REPAIR D-1) Check Voltage and Phase: Before operating pump, compare the voltage and phase NOTE: All item numbers in ( ) refer to Figures 12 & 13. information stamped on the pump identifi cation plate to the available power. - Page 8 F-2) Impeller and Volute Service: F-2.1) Disassembly and Inspection: To clean out volute (25) disconnect power, remove hex nuts (19), and lock washers (18), vertically lift motor and seal plate assembly from volute (25). Clean out volute if necessary. Clean and examine impeller (27), for pitting or wear and replace if required, inspect square ring (36) and replace if cut or damaged.
- Page 9 Check motor capacitor (3, 1 phase units) with an Ohm meter by fi rst grounding the capacitor by placing a screwdriver across both terminals and then removing screwdriver. Connect Ohm meter (set on high scale) to terminals. If needle moves to infi nity (∞) then drifts back, the capacitor is good. If needle does not move or moves to infi...
- Page 10 that it will lay on the opposite side of the cord entry bosses Reconnect motor and control leads to the underside of the of the motor housing (2). Reconnect capacitor leads. Torque terminal block(s) (21), (26) as shown in Figures 5 and 11. motor tie bolts to 22 in-lbs.
-
Page 11: Replacement Parts
Seal - To expose shaft seal (38) for examination, complete Make sure driving lugs in retainer are matched in rotating above procedure and slide off outboard rotating member member. Place spring (38C) over shaft and in place on (38B) (see Figure 7). Remove inboard rotating member rotating member (38E), making sure it is seated in retainer (38D), from shaft. -
Page 12: Wiring Schematics
FIGURE 11... -
Page 13: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”... -
Page 14: Cross-Section 3Se-Ds 1750Rpm (Fig. 12)
3SE-DS 1750RPM OIL LEVEL 30 48 FIGURE 12... -
Page 15: Exploded View 3Se-Ds 1750Rpm (Fig. 13)
3SE-DS 1750RPM FIGURE 13... -
Page 16: Parts List 3Se-Ds 1750Rpm
Pressure Gauge Kit...P/N-085343 PARTS LIST ITEM PART NO. DESCRIPTION NOTES 088758 Motor, 3SE3024DS 088763 Motor, 3SE3034DS, 3SE3044DS 088766 Motor, 3SE3054DS 114492 Motor Housing No Sensors 114492HA Motor Housing 036391 Capacitor, 370V, 45 MFD 1 Phase 026322 Lock washer 5/16” Stainless 014270 3/8”... - Page 17 POWER 3SE3024DS 103769XC 103769XF 103769XL 103760 3SE3034DS 109492XC 109492XF 109492XL 103586 3SE3044DS 103742XC 103742XF 103742XL 103583 3SE3054DS 103742XC 103742XF 103742XL 103583 TERMINAL BLOCK MODEL NUMBER 30 FT. SENSOR 50 FT. SENSOR 100 FT. SENSOR SENSOR 3SE3024DS ------ ------ ------ ------...
-
Page 19: Warranty
IMPORTANT! WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. To complete the Warranty Registration Form go to: http://www.cranepumps.com/ProductRegistration/ If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. - Page 20 Notes...
