INSTALLATION and OPERATION MANUAL
Self-Priming Centrifugal Pumps
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
BARNES
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Electric Drive Models:
3CCE, 3CCE-1
4CCE, 4CCE-1
5CCE, 5CCE-1
10CCE, 10CCE-1
15CCE
20CCE
25CCE
Form No. 022567-Rev. V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3CCE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Barnes 3CCE

  • Page 1 Manual Index BARNES BARNES ® INSTALLATION and OPERATION MANUAL Self-Priming Centrifugal Pumps Electric Drive Models: 3CCE, 3CCE-1 4CCE, 4CCE-1 5CCE, 5CCE-1 10CCE, 10CCE-1 15CCE 20CCE 25CCE IMPORTANT! Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur.
  • Page 2: Table Of Contents

    START-UP REPORT ..................23 - 24 WARRANTY REGISTRATION Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1984, 2002, 6/03, 1/04, 2/06, 4/06, 5/06, 8/06 Alteration Rights Reserved...
  • Page 3: Safety First

    SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This information is provided for SAFETY and to PREVENT CAUTION! - Do not block or restrict discharge hose, as EQUIPMENT PROBLEMS. To help recognize this information, discharge hose may whip under pressure. observe the following symbols: IMPORTANT! Warns about hazards that can result WARNING! - DO NOT wear loose clothing that may...
  • Page 4: Pump Specifications

    SECTION: A - PUMP SPECIFICATIONS: 3CCE, 4CCE, 5CCE DISCHARGE ....1½” (38mm) x 1½ (38mm) NPT , CHECK VALVE: Female Material ..Valve Flap - Neoprene LIQUID TEMPERATURE 160°F (71°C) Continuous Weight - Cast Iron ASTM A-48, Class 30 INTERMEDIATE ..... Cast Iron ASTM A-48, Class 30 VOLUTE ......
  • Page 5 SECTION: A - PUMP SPECIFICATIONS: 10CCE, 10CCE-1 DISCHARGE ....2” (51mm) x 2” (51mm) NPT , SHAFT SLEEVE .... Bronze Female CHECK VALVE: LIQUID TEMPERATURE 160°F (71°C) Continuous Material ..Valve Flap - Neoprene INTERMEDIATE ..... Cast Iron ASTM A-48, Class 30 Weight - Cast Iron ASTM A-48, Class 30 VOLUTE ......
  • Page 6 SECTION: A - PUMP SPECIFICATIONS: 15CCE DISCHARGE ....3” (76mm) x 3” (76mm) NPT , SHAFT SLEEVE .... Bronze Female CHECK VALVE: LIQUID TEMPERATURE 160°F (71°C) Continuous Material ..Valve Flap - Neoprene INTERMEDIATE ..... Cast Iron ASTM A-48, Class 30 Weight - Cast Iron ASTM A-48, Class 30 VOLUTE ......
  • Page 7 SECTION: A - PUMP SPECIFICATIONS: 20CCE DISCHARGE ....3” (76mm) x 3” (76mm) NPT , SHAFT SLEEVE .... Bronze Female CHECK VALVE: LIQUID TEMPERATURE 160°F (71°C) Continuous Material ..Valve Flap - Neoprene INTERMEDIATE ..... Cast Iron ASTM A-48, Class 30 Weight - Cast Iron ASTM A-48, Class 30 VOLUTE ......
  • Page 8 SECTION: A - PUMP SPECIFICATIONS: 25CCE DISCHARGE ....3” (76mm) x 3” (76mm) NPT , SHAFT SLEEVE .... Bronze Female CHECK VALVE: LIQUID TEMPERATURE 160°F (71°C) Continuous Material ..Valve Flap - Neoprene INTERMEDIATE ..... Cast Iron ASTM A-48, Class 30 Weight - Cast Iron ASTM A-48, Class 30 VOLUTE ......
  • Page 9: General Information

    (sum of absolute values) of rated values, provided the frequency variation does not exceed ± 5% of rated frequency. B-4) SERVICE CENTERS: For the location of the nearest Barnes Service Center, check your Barnes representative or Barnes Service Department in C-6) Pump Lubrication: The pump requires no lubrication.
  • Page 10: Pump Service And Repair

    fl ushing the solids out of the body. Replace the drain plug. Remove cap screws (5), lockwashers (6) to remove motor (1), and base (7) (On 3CCE - 5CCE’s). To remove motor (1) from D-4) Restart: At each subsequent start, particularly if the pump has been base (7) on 10CCE - 25CCE’s, remove cap screws (28) on...
  • Page 11: Trouble Shooting

    TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. SYMPTOM POSSIBLE CAUSE(S) Little or no discharge 1. Casing not fi lled with water 1.
  • Page 12: Cross-Section, 3Cce - 5Cce

    SERIES: 3CCE, 3CCE-1, 4CCE, 4CCE-1, 5CCE, 5CCE-1...
  • Page 13: Exploded View, 3Cce - 5Cce

    SERIES: 3CCE, 3CCE-1, 4CCE, 4CCE-1, 5CCE, 5CCE-1...
  • Page 14: Parts List, 3Cce - 5Cce

    SERIES: 3CCE, 3CCE-1, 4CCE, 4CCE-1, 5CCE, 5CCE-1 PARTS KIT Seal Kit ..... P/N: 021814 (‡) 3,4,9,10,11,16,17,22C 4CCE Parts Kit...P/N: 083862 (▲) 2, 3, 4, 5, 9, 10, 11, 12, 13, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26...
  • Page 15: Cross-Section, 10Cce, 10Cce-1

    SERIES: 10CCE, 10CCE-1...
  • Page 16: Exploded View, 10Cce, 10Cce-1

    SERIES: 10CCE, 10CCE-1...
  • Page 17: Parts List, 10Cce, 10Cce-1

    SERIES: 10CCE, 10CCE-1 PARTS KIT Seal Kit ....P/N: 072920 (‡) 3,4,8,9,10,11,16,17,22C PARTS LIST ITEM QTY. PART No. DESCRIPTION 028495 Motor - 10CCE 200-230/460, ODP 028494 Motor - 10CCE-1 230, ODP 036770 Motor - 10CCE 200-230/460, TEFC 028494F Motor - 10CCE-1 230, TEFC 019537 Intermediate Coupling 005163 ‡...
  • Page 18: Cross-Section, 15Cce, 20Cce, 25Cce

    SERIES: 15CCE, 20CCE, 25CCE...
  • Page 19: Exploded View, 15Cce, 20Cce, 25Cce

    SERIES: 15CCE, 20CCE, 25CCE...
  • Page 20: Parts List, 15Cce, 20Cce, 25Cce

    SERIES: 15CCE, 20CCE, 25CCE PARTS KIT Seal Kit ..... P/N: 072918 (‡) 3, 4, 8, 9, 10, 11, 16, 17, 22C PARTS LIST ITEM QTY. PART No. DESCRIPTION 028496 Motor - 15CCE 200-230/460, ODP 028497 Motor - 20CCE 200-230/460, ODP 028498 Motor - 25CCE 200-230/460, ODP...
  • Page 22: Returned Goods Policy

    IMPORTANT! WARRANTY REGISTRATION Your product is covered by the enclosed Warranty. To complete the Warranty Registration Form go to: http://www.cranepumps.com/ProductRegistration/ If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”.
