Installation

© Danfoss | ADAP-KOOL® | 2018.11
The MCX-RTU is mounted on a DIN rail with enough room to easily connect power and other
interface wires.
This image provides the dimensions of the MCX-RTU controller for determining space for
mounting. Make sure that you allow enough space for easy routing of the required interface
cables for power, inputs and outputs.
The MCX-RTU must be mounted in a space that meets the environmental standards named in
the specification section of this document.
280 63 60
