Display Panel - Magicfx SPARXTAR SPARK FX User And Installation Manual

DMX Address
Safety address
Start address
(Effect height)
Start address + 1
(Effect trigger)
NOTICE
NOTICE
1.7

DISPLAY PANEL

The display panel is located on the backside of the MAGICFX
following menu structure for all options in the menu. Use the buttons for navigation
and selection. The left-hand LED blinks red when DMX is active. The right-hand LED
continuously lights red when an error is present.
8 MAGICFX® SPARXTAR — User and Installation Manual
DMX Value (decimal)
0 99
100 154
155 255
0 255
0 63
64 127
128 255
The maximum continuous duration of the effect is 40 seconds.
After this period the effect will stop automatically. To start the
effect again you must disable and re-enable the Effect trigger.
Always plug in a DMX Terminator into the DMX output of the final
unit in the control sequence. Using a DMX Terminator improves
signal reliability.
MAIN MENU
DMX/RDM SETTINGS
BACK PREV
Result
Device disabled
Device enabled
Device disabled
Effect height (2 to 4.5 m)
No output
Empty heater (only when previously
set to 'no output' and after a delay of
10 seconds)
Output effect at set height
Operation of the DMX addresses
NEXT SELECT
®
Display panel
SPARXTAR. Check the
