1.8

RDM CAPABILITY

Remote Device Management Protocol (RDM) is an enhancement of the DMX512
communication protocol. RDM can be used for configuration and status monitoring
while DMX512 takes care of the default controlling.
For RDM you will need a RDM compatible controller.
The following RDM parameters are supported by the MAGICFX
Parameter ID
DISC_UNIQUE_BRANCH
DISC_MUTE
DISC_UN_MUTE
DEVICE_INFO
SUPPORTED_PARAMETERS
SOFTWARE_VERSION_LABEL
DEVICE_MODEL_DESCRIPTION
MANUFACTURER_LABEL
SLOT_DESCRIPTION
DMX_PERSONALITY_DESCRIPTION
SENSOR_DEFINITION
SENSOR_VALUE
DMX_START_ADDRESS
IDENTIFY_DEVICE
DEVICE_LABEL
FACTORY_DEFAULTS
DMX_PERSONALITY
RESET_DEVICE
RDM parameters are subject of change due to software updates. Contact MAGIC FX
for the latest information and updates.
10 MAGICFX® SPARXTAR — User and Installation Manual
Discovery
X
X
X
SPARXTAR.
®
GET SET
X
X
X
X
X
X
X
X
X
X
X
X
X
X
RDM parameters
X
X
X
X
X
X
