Exerpeutic 900XL Owner's Manual page 15

ASSEMBLY
Tool:
Multi Hex Tool with Phillips
Screwdriver
STEP 4
The Cranks, Foot Pedals, Pedal Shafts and Pedal Straps are marked "R" for
Note:
Right and "L" for Left.
4a. Installing the Left Pedal: Insert the threaded shaft of the Left Foot Pedal (60) into the
threaded hole on the Left Crank (46). Turn the pedal shaft by hand in a counter-clockwise
direction until snug. Finish off the tightening of the Left Foot Pedal (60) in the same direction as
instructed with the Multi Hex Tool with Phillips Screwdriver.
4b. Installing the Right Pedal: Insert the threaded shaft of the Right Foot Pedal (59) into the
threaded hole on the Right Crank (46). Turn the pedal shaft by hand in a clockwise direction until
snug. Finish off the tightening of the Right Foot Pedal (59) in the same direction as instructed with
the Multi Hex Tool with Phillips Screwdriver.
WARNING: Tighten the pedal shaft in the direction instructed for the Right Foot Pedal (59) and
Left Foot Pedal (60). Failing to do so may strip the threads on the pedal shafts. Insert the pedal
shaft of Left Foot Pedal (60) into threaded hole in the Left Crank (46). Turn the pedal shaft by
hand in the counter-clockwise direction until snug.
Note: DO NOT turn the pedal shaft in the clockwise direction, doing so will strip the threads.
13
