⑤Show Steep Overhang

[View]--[Show Steep
Click
model surface and horizontal line is within the overhang threshold value, the surface
has steep overhang and it becomes red in the software. Overhang threshold value
could be set as needed. The default value is 45 degree.
6.2.5

Move

Select the object and move the object by the following two methods:
Method 1: Click the
drag to adjust the location of the model in XY direction. Hold down the
hold down the left mouse button and drag to adjust the location of the model in Z
direction. The distance and the direction of the movement shall be displayed.
Method 2: Click the
[Reset] to reset distance values.
Note: Users shall click
ensure the model(s) be within the build area and on the build platform. If a specified
position is needed, only click
6.2.6

Rotate

Select the target object and rotate the object by the following two methods:
Method 1: Click the
appear around the object Click one ring and rotate on the present axis, you will see the
rotation angle and direction in the center of circle. In this way, you could make the
model rotate on X/Y/Z axis.
Method 2: Click the
values in X/Y/Z axes positioning. Click
Creator3 User Guide | www.flashforge.com
Overhang]. When the intersection angle between the
[Move] icon on the left, hold down the left mouse button and
[Move] button on the left and then enter the distance value. Click
[Center] and [On Platform]
[On Platform].
[Rotate]
icon on the left and three mutually perpendicular rings
[Rotate] icon on the left, and then enter into rotating angel
[Reset]
after the location adjustment to
to reset rotating angel values.
54
Shift key,
