AXIOMTEK CEM700 User Manual page 18

CEM700 COM Express
Pin Signal
A1 GND_A1 (FIXED)
A2 GBE0_MDI3-
A3 GBE0_MDI3+
A4 GBE0_LINK100#
A5 GBE0_LINK1000#
A6 GBE0_MDI2-
A7 GBE0_MDI2+
A8 GBE0_LINK#
A9 GBE0_MDI1-
A10 GBE0_MDI1+
A11 GND_A11 (FIXED)
A12 GBE0_MDI0-
A13 GBE0_MDI0+
A14 GBE0_CTREF
A15 SUS_S3#
A16 SATA0_TX+
A17 SATA0_TX-
A18 SUS_S4#
A19 SATA0_RX+
A20 SATA0_RX-
A21 GND_A21 (FIXED)
A22 PCIE_TX15+
A23 PCIE_TX15-
A24 SUS_S5#
A25 PCIE_TX14+
A26 PCIE_TX14-
A27 BATLOW# [1]
A28 (S)ATA_ACT#
A29 RSVD_A29 [1]
A30 RSVD_A30 [1]
A31 GND_A31 (FIXED)
A32 RSVD_A32 [1]
A33 RSVD_A33 [1]
A34 BIOS_DIS0#/ESPI_SAFS
A35 THRMTRIP#
A36 PCIE_TX13+
A37 PCIE_TX13-
A38 GND_A38
A39 PCIE_TX12+
A40 PCIE_TX12-
A41 GND_A41 (FIXED)
A42 USB2-
A43 USB2+
A44 USB_2_3_OC#
A45 USB0-
A46 USB0+
A47 VCC_RTC
A48 RSVD_A48
[1]
A49 GBE0_SDP
A50 LPC_SERIRQ/ESPI_CS1#
[2]
A51 GND_A51 (FIXED)
A52 PCIE_TX5+
A53 PCIE_TX5-
A54 GPI0
A55 PCIE_TX4+
[1]
Not connected on the CEM700.
[2]
CEM700 doesn't support ESPI. The voltage of these pins is 3.3V.
12
TM
Type 7 Basic Module
Pin Signal
B1 GND_B1 (FIXED)
B2 GBE0_ACT#
B3 LPC_FRAME#/ESPI_CS0#
B4 LPC_AD0/ESPI_IO_0 [2]
B5 LPC_AD1/ESPI_IO_1 [2]
B6 LPC_AD2/ESPI_IO_2 [2]
B7 LPC_AD3/ESPI_IO_3
[2]
B8 LPC_DRQ0#/ESPI_ALERT0#
B9 LPC_DRQ1#/ESPI_ALERT1#
B10 LPC_CLK/ESPI_CLK [2]
B11 GND_B11 (FIXED)
B12 PWRBTN#
B13 SMB_CK
B14 SMB_DAT
B15 SMB_ALERT#
B16 SATA1_TX+
B17 SATA1_TX-
B18 SUS_STAT#/ESPI_RESET#
B19 SATA1_RX+
B20 SATA1_RX-
B21 GND_B21 (FIXED)
B22 PCIE_RX15+
B23 PCIE_RX15-
B24 PWR_OK
B25 PCIE_RX14+
B26 PCIE_RX14-
B27 WDT
B28 RSVD_B28 [1]
B29 RSVD_B29 [1]
B30 RSVD_B30 [1]
B31 GND_B31 (FIXED)
B32 SPKR
B33 I2C_CK
B34 I2C_DAT
B35 THRM# [1]
B36 PCIE_RX13+
B37 PCIE_RX13-
B38 GND_B38
B39 PCIE_RX12+
B40 PCIE_RX12-
B41 GND_B41 (FIXED)
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47 ESPI_EN# [1]
B48 USB0_HOST_PRSNT
[1]
B49 SYS_RESET#
B50 CB_RESET#
B51 GND_B51 (FIXED)
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
Pin Signal
C1 GND_C1 (FIXED)
C2 GND_C2
C3 USB_SSRX0-
[2]
C4 USB_SSRX0+
C5 GND_C5
C6 USB_SSRX1-
C7 USB_SSRX1+
[2] C8 GND_C8
C9 USB_SSRX2-
[2]
C10 USB_SSRX2+
C11 GND_C11 (FIXED)
C12 USB_SSRX3-
C13 USB_SSRX3+
C14 GND_C14
C15 10G_PHY_MDC_SCL3
C16 10G_PHY_MDC_SCL2
C17 10G_SDP2
[1]
[2] C18 GND_C18
C19 PCIE_RX6+
C20 PCIE_RX6-
C21 GND_C21 (FIXED)
C22 PCIE_RX7+
C23 PCIE_RX7-
C24 10G_INT2 [1]
C25 GND_C25
C26 10G_KR_RX3+ [1]
C27 10G_KR_RX3- [1]
C28 GND_C28
C29 10G_KR_RX2+ [1]
C30 10G_KR_RX2- [1]
C31 GND_C31 (FIXED)
C32 10G_SFP_SDA3 [1]
C33 10G_SFP_SDA2 [1]
C34 10G_PHY_RST_23
[1]
C35 10G_PHY_RST_01
C36 10G_LED_SDA
C37 10G_LED_SCL
C38 10G_SFP_SDA1
C39 10G_SFP_SDA0
C40 10G_SDP0
C41 GND_C41 (FIXED)
C42 10G_KR_RX1+
C43 10G_KR_RX1-
C44 GND_C44
C45 10G_PHY_MDC_SCL1
C46 10G_PHY_MDC_SCL0
C47 10G_INT0
C48 GND_C48
C49 10G_KR_RX0+
C50 10G_KR_RX0-
C51 GND_C51 (FIXED)
C52 PCIE_RX16+
C53 PCIE_RX16-
C54 TYPE0#
C55 PCIE_RX17+
Module and Pin Assignments
Pin Signal
D1 GND_D1 (FIXED)
D2 GND_D2
D3 USB_SSTX0-
D4 USB_SSTX0+
D5 GND_D5
D6 USB_SSTX1-
D7 USB_SSTX1+
D8 GND_D8
D9 USB_SSTX2-
D10 USB_SSTX2+
D11 GND_D11 (FIXED)
D12 USB_SSTX3-
D13 USB_SSTX3+
D14 GND_D14
D15 10G_PHY_MDIO_SDA3
[1]
[1] D16 10G_PHY_MDIO_SDA2
D17 10G_SDP3
[1]
D18 GND_D18
D19 PCIE_TX6+
D20 PCIE_TX6-
D21 GND_D21 (FIXED)
D22 PCIE_TX7+
D23 PCIE_TX7-
D24 10G_INT3 [1]
D25 GND_D25
D26 10G_KR_TX3+ [1]
D27 10G_KR_TX3- [1]
D28 GND_D28
D29 10G_KR_TX2+ [1]
D30 10G_KR_TX2- [1]
D31 GND_D31 (FIXED)
D32 10G_SFP_SCL3 [1]
D33 10G_SFP_SCL2 [1]
D34 10G_PHY_CAP_23
[1]
D35 10G_PHY_CAP_01
D36 RSVD_D36 [1]
D37 RSVD_D37 [1]
D38 10G_SFP_SCL1
D39 10G_SFP_SCL0
D40 10G_SDP1
D41 GND_D41 (FIXED)
D42 10G_KR_TX1+
D43 10G_KR_TX1-
D44 GND_D44
D45 10G_PHY_MDIO_SDA1
D46 10G_PHY_MDIO_SDA0
D47 10G_INT1
D48 GND_D48
D49 10G_KR_TX0+
D50 10G_KR_TX0-
D51 GND_D51 (FIXED)
D52 PCIE_TX16+
D53 PCIE_TX16-
D54 RSVD_D54
[1]
D55 PCIE_TX17+
[1]
[1]
