  • Page 1 CEM510 ® Generation Intel Core i7/ i5/ i3 Processors COM Express Type 6 Basic Module User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.

  • Page 3: Esd Precautions

    It discharges static electricity from your body.  Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® ® Intel , Celeron are trademarks of Intel Corporation.

  • Page 4: Table Of Contents

    Table of Contents Disclaimers ..................... ii ESD Precautions ................... iii Chapter 1 Introduction ..........1 Features ....................1 Specifications ..................2 Utilities Supported ................3 Chapter 2 Module and Pin Assignments ....5 Module Dimensions and Fixing Holes ..........5 Module Layout ..................
  • Page 5 Boot Menu ..................49 Save & Exit Menu ................51 Appendix A Watchdog Timer and GPIO ....53 About Watchdog Timer ..............53 About GPIO ..................53 Appendix B BIOS Flash Utility ........ 55 Appendix C iAMT Settings ........59 Entering MEBx ...................
  • Page 6 This page is intentionally left blank.

  • Page 7: Chapter 1 Introduction

    CEM510 COM Express Type 6 Basic Module Chapter 1 Introduction The CEM510 is a COM Express Type 6 Basic Module powered by BGA type quad/dual core ® ® generation Intel Core processors. integrates Intel QM175/HM175/CM238 chipset which supports the most updated high speed I/Os like PCI-Express Gen 3 at 8GT/s, SuperSpeed USB 3.0 at 5Gb/s, and SATA-600 at 6Gb/s.

  • Page 8: Specifications

    CEM510 COM Express Type 6 Basic Module Specifications  ®  generation Intel Core i7/ i5/ i3 BGA processors.  Chipset ®  Intel QM175/HM175/CM238 Express chipset.  BIOS  American Megatrends Inc. BIOS.  128Mbit SPI Flash, DMI, Plug and Play.

  • Page 9: Utilities Supported

    CEM510 COM Express Type 6 Basic Module Utilities Supported ®  Intel QM175/HM175/CM238 utility and driver  Graphics driver  Ethernet utility and driver  ME driver All specifications and images are subject to change without notice. Note Introduction...
  • Page 10 CEM510 COM Express Type 6 Basic Module This page is intentionally left blank. Introduction...

  • Page 11: Module And Pin Assignments

    CEM510 COM Express Type 6 Basic Module Chapter 2 Module and Pin Assignments Module Dimensions and Fixing Holes Top View Module and Pin Assignments...
  • Page 12 CEM510 COM Express Type 6 Basic Module Bottom View Module and Pin Assignments...

  • Page 13: Module Layout

    CEM510 COM Express Type 6 Basic Module Module Layout Top View Module and Pin Assignments...
  • Page 14 CEM510 COM Express Type 6 Basic Module Bottom View Module and Pin Assignments...

  • Page 15: Installing Thermal Solution

    This CPU module has six assembly holes for installing heatsink plate. Use the six screws to secure the heatsink plate to the CEM510. Be careful not to over-tighten the screws. Module and Pin Assignments...

  • Page 16: Switch Settings

    Type 6 Basic Module Switch Settings Properly configure switch settings on the CEM510 to meet your application purpose. Below you can find a summary table of all switches and onboard default settings. Once the default switch setting needs to be changed, please do it under power-off condition.

  • Page 17: Connectors

    CEM510 COM Express Type 6 Basic Module Connectors Signals go to the other parts of the system through connectors. Loose or improper connection might cause problems, please make sure all connectors are properly and firmly connected. Here is a summary table which shows connectors on the hardware.
  • Page 18 CEM510 COM Express Type 6 Basic Module Signal Signal Signal Signal GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) GBE0_MDI3- GBE0_ACT# GND (FIXED) GND (FIXED) GBE0_MDI3+ LPC_FRAME# USB_SSRX0- USB_SSTX0- GBE0_LINK100# LPC_AD0 USB_SSRX0+ USB_SSTX0+ GBE0_LINK1000# LPC_AD1 GND (FIXED) GND (FIXED) GBE0_MDI2-...
  • Page 19 CEM510 COM Express Type 6 Basic Module Signal Signal Signal Signal PCIE_TX4- PCIE_RX4- PEG_RX1- PEG_TX1- GPO2 TYPE1# TYPE2# PCIE_TX3+ PCIE_RX3+ PEG_RX2+ PEG_TX2+ PCIE_TX3- PCIE_RX3- PEG_RX2- PEG_TX2- GND (FIXED) GND (FIXED) GND (FIXED) GND (FIXED) PCIE_TX2+ PCIE_RX2+ PEG_RX3+ PEG_TX3+ PCIE_TX2- PCIE_RX2-...
  • Page 20 CEM510 COM Express Type 6 Basic Module This page is intentionally left blank. Module and Pin Assignments...

  • Page 21: Chapter 3 Hardware Description

    You must install the heatsink or cooler carefully and properly to prevent damage. BIOS The CEM510 uses AMI Plug and Play BIOS with a single 128Mbit SPI Flash. System Memory The CEM510 supports two 260-pin DDR4 2133MHz SO-DIMM sockets for maximum memory capacity up to 32GB DDR4 SDRAMs (CM238 supports ECC memory).

  • Page 22: I/O Port Address Map

    CEM510 COM Express Type 6 Basic Module I/O Port Address Map ® The I/O port addresses (with CEB940011 baseboard under Windows 10) are as follows: Hardware Description...

  • Page 23: Interrupt Controller (Irq) Map

    CEM510 COM Express Type 6 Basic Module Interrupt Controller (IRQ) Map ® The interrupt controller (IRQ) mapping list (with CEB940011 baseboard under Windows 10) is shown as follows: Hardware Description...
  • Page 24 CEM510 COM Express Type 6 Basic Module Hardware Description...
  • Page 25 CEM510 COM Express Type 6 Basic Module Hardware Description...
  • Page 26 CEM510 COM Express Type 6 Basic Module Hardware Description...
  • Page 27 CEM510 COM Express Type 6 Basic Module Hardware Description...

  • Page 28: Memory Map

    CEM510 COM Express Type 6 Basic Module Memory Map ® The memory (with CEB940011 baseboard under Windows 10) mapping list is shown as follows: Hardware Description...

  • Page 29: Ami Bios Setup Utility

    CEM510 COM Express Type 6 Basic Module Chapter 4 AMI BIOS Setup Utility The AMI UEFI BIOS provides users with a built-in setup program to modify basic system configuration. All configured parameters are stored in a flash chip to save the setup information whenever the power is turned off.
  • Page 30 CEM510 COM Express Type 6 Basic Module Hot Keys Description  Left/Right The Left and Right <Arrow> keys allow you to select a setup screen. The Up and Down <Arrow> keys allow you to select a setup screen or sub ...

  • Page 31: Main Menu

    CEM510 COM Express Type 6 Basic Module Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 32: Advanced Menu

    CEM510 COM Express Type 6 Basic Module Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 33 CEM510 COM Express Type 6 Basic Module  Serial Port Configuration You can use this screen to select options for Serial Port Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 34 CEM510 COM Express Type 6 Basic Module  Serial Port 1 Configuration Serial Port Enable or disable serial port 1. The optimal setting for base I/O address is 248h and for interrupt request address is IRQ7.  Serial Port 2 Configuration Serial Port Enable or disable serial port 2.
  • Page 35 CEM510 COM Express Type 6 Basic Module  Hardware Monitor This screen is for fan speed control and hardware health status monitoring. This screen displays the temperature of system and CPU, cooling fans speed in RPM and system voltages (VBAT, +3.3V, +3.3VSB and +5VSB).
  • Page 36 CEM510 COM Express Type 6 Basic Module Smart Fan1/2 Mode Select Set Smart Fan 1/2 mode. The default is Auto Mode. If Smart Fan is in Auto Mode, the system fan spins at different speed depending on system temperature; the higher the temperature, the faster the system fan spins.
  • Page 37 CEM510 COM Express Type 6 Basic Module  ACPI Settings You can use this screen to select options for system ACPI configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 38 CEM510 COM Express Type 6 Basic Module  Trusted Computing You can use this screen for TPM (Trusted Platform Module) configuration. It also shows current TPM status information. Security Device Support Enable or disable BIOS support for security device. The default is Disabled. Once the Security Device Support is enabled, you will see the following screen.
  • Page 39 CEM510 COM Express Type 6 Basic Module  CPU Configuration This screen shows the CPU Configuration, and you can change the value of the selected option. Hyper-threading Enable or disable Hyper-threading Technology, which allows a single physical processor to multitask as multiple logical processors. When disabled, only one thread per enabled core is enabled.
  • Page 40 CEM510 COM Express Type 6 Basic Module  SATA and RST Configuration In the SATA Configuration menu, you can see the currently installed hardware in the SATA ports. During system boot up, the BIOS automatically detects the presence of SATA devices.
  • Page 41 CEM510 COM Express Type 6 Basic Module  PCH-FW Configuration This screen displays ME Firmware information.  AMT Configuration Use this screen to configure AMT parameters. AMT BIOS Features Active Management Technology BIOS Extension is enabled. Please refer to Appendix C for iAMT settings.
  • Page 42 CEM510 COM Express Type 6 Basic Module  USB Configuration USB Devices Display all detected USB devices. Mass Storage Devices Mass storage device emulation type. Auto option enumerates devices according to their media format. Optical drives are emulated as CDROM, drives with no media will be emulated according to a drive type.
  • Page 43 CEM510 COM Express Type 6 Basic Module  Serial Port Console Redirection You can use this screen to select options for Serial Port Console Redirection, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 44 CEM510 COM Express Type 6 Basic Module UART1\UART2 Console Redirection Settings When enabled, the settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings.
  • Page 45 CEM510 COM Express Type 6 Basic Module  Device Configuration A description of selected item appears on the right side of the screen. For items marked with “”, please press <Enter> for more options. Onboard Device Configuration Use this option to configure onboard device (e.g., Digital I/O setting).
  • Page 46 CEM510 COM Express Type 6 Basic Module DIO Modification Enable or disable digital I/O modification. The default is Disabled. DIO port 1-8 Select this option to open DIO status sub screen. AMI BIOS Setup Utility...
  • Page 47 CEM510 COM Express Type 6 Basic Module If DIO Modification is disabled, you are not allowed to change inputs/outputs setting. The DIO status sub screen is as follows: After enabling, you can load manufacture default and access to the DIO status sub screen to change inputs/outputs setting, see images below.

  • Page 48: Chipset Menu

    CEM510 COM Express Type 6 Basic Module Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 49 CEM510 COM Express Type 6 Basic Module  System Agent (SA) Configuration This screen allows users to configure System Agent (SA) parameters. For items marked with “”, please press <Enter> for more options. Graphics Configuration Open sub menu for parameters related to graphics configuration.
  • Page 50 CEM510 COM Express Type 6 Basic Module  Graphics Configuration DDI1 Signal Select Select the DDI1 signal output to DisplayPort or HDMI/DVI. DDI2 Signal Select Select the DDI2 signal output to DisplayPort or HDMI/DVI. AMI BIOS Setup Utility...
  • Page 51 CEM510 COM Express Type 6 Basic Module Primary IGFX Boot Display Select the video device which will be activated during POST (Power-On Self Test). The default is Auto. The Secondary IGFX Boot Display selection appears only if you set this option to DDI1, DDI2, DDI3 or LVDS, see image below.
  • Page 52 CEM510 COM Express Type 6 Basic Module Secondary IGFX Boot Display Select secondary IGFX boot display. LVDS Panel Type Select LVDS panel resolution. AMI BIOS Setup Utility...
  • Page 53 CEM510 COM Express Type 6 Basic Module Backlight Control This item is for backlight control setting. Selection options are PWM Inverted and PWM Normal.  Memory Configuration This screen shows the system memory information. AMI BIOS Setup Utility...

  • Page 54: Security Menu

    CEM510 COM Express Type 6 Basic Module Security Menu The Security menu allows users to change the security settings for the system.  Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled).  User Password This item indicates whether a user password has been set (installed or uninstalled).

  • Page 55: Boot Menu

    CEM510 COM Express Type 6 Basic Module Boot Menu The Boot menu allows users to change boot options of the system.  Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.
  • Page 56 CEM510 COM Express Type 6 Basic Module  Launch PXE OpROM policy Use this item to enable or disable the boot ROM function of the onboard LAN chip when the system boots up. Boot Option Priorities [Boot Option #1, ……] ...

  • Page 57: Save & Exit Menu

    CEM510 COM Express Type 6 Basic Module Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values.  Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 58 CEM510 COM Express Type 6 Basic Module  Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes.

  • Page 59: Appendix A Watchdog Timer And Gpio

    CEM510 COM Express Type 6 Basic Module Appendix A Watchdog Timer and GPIO A.1 About Watchdog Timer After the system stops working for a while, it can be auto-reset by the watchdog timer. The integrated watchdog timer can be set up in the system reset mode by program.
  • Page 60 CEM510 COM Express Type 6 Basic Module This page is intentionally left blank. Watchdog Timer and GPIO...

  • Page 61: Appendix Bbios Flash Utility

    Please read and follow the instructions below carefully. In your USB flash drive, create a new folder and name it “Axiomtek”, see figure below. Copy BIOS ROM file (e.g. CEM510X.005) to “Axiomtek” folder.
  • Page 62 Select the USB drive containing BIOS ROM file you want to update using the <> or <> key. Then press <Enter> to get into “Axiomtek” folder. Now you can see the BIOS ROM file on the screen, press <Enter> to select.
  • Page 63 CEM510 COM Express Type 6 Basic Module Please wait while BIOS completes the entire flash update process: erase data, write new data and verify data. 10. When you see the following figure, press <Enter> to finish the update process. After that the system will shut down and restart immediately.
  • Page 64 CEM510 COM Express Type 6 Basic Module This page is intentionally left blank. BIOS Flash Utility...

  • Page 65: Appendix C Iamt Settings

    CEM510 COM Express Type 6 Basic Module Appendix C iAMT Settings ® ® The Intel Active Management Technology (Intel iAMT) has decreased a major barrier to IT efficiency that uses built-in platform capabilities and popular third-party management and security applications to allow IT a better discovering, healing, and protection their networked computing assets.
  • Page 66 CEM510 COM Express Type 6 Basic Module You will be asked to change the password before setting ME. You must confirm your new password while revising. The new password must contain: (example: !!11qqQQ) (default value).  Eight characters  One upper case ...
  • Page 67 CEM510 COM Express Type 6 Basic Module From Main Menu, select ME General Settings to get into ME Platform Configuration screen. In this screen you can modify Local FW Update setting. Return to Main Menu. iAMT Settings...

  • Page 68: Iamt Settings

    CEM510 COM Express Type 6 Basic Module iAMT Settings ® Select Intel AMT configuration and press <Enter>. From AMT Configuration menu, select Manageability Feature Selection and set it to Enabled. ® This item allows you to enable or disable Intel AMT feature.
  • Page 69 CEM510 COM Express Type 6 Basic Module  Network Setup 1. Select Network Setup to configure iAMT. 2. Select ME Network Name Settings to set computer host and domain name. iAMT Settings...
  • Page 70 CEM510 COM Express Type 6 Basic Module 3. Select TCP/IP to get into Network interface and set it to Enabled. Get into DHCP Mode and set it to Disabled. iAMT Settings...
  • Page 71 CEM510 COM Express Type 6 Basic Module 4. If DHCP Mode is disabled, set the following settings:  IP address  Subnet mask iAMT Settings...
  • Page 72 CEM510 COM Express Type 6 Basic Module 5. Go back to Intel® iAMT Configuration, then select Activate Network Access and press <Enter>. 6. Exit from MEBx after completing the iAMT settings. iAMT Settings...

  • Page 73: Iamt Web Console

    CEM510 COM Express Type 6 Basic Module iAMT Web Console From a web browser, please type http://(IP ADDRESS):16992, which connects to iAMT Web. Example: http://10.1.40.214:16992 To log on, you will be required to type in username and password for access to the Web.
  • Page 74 CEM510 COM Express Type 6 Basic Module Enter the iAMT Web. iAMT Settings...
  • Page 75 CEM510 COM Express Type 6 Basic Module Click Remote Control, and select commands on the right side. When you have finished using the iAMT Web console, close the Web browser. iAMT Settings...
