How to Install

6.2.3 Wiring

Supply voltage must be connected to the terminals X1.1, X1.2
and X1.3. The frequency converter supply terminals L1, L2 and
L3 must be connected to the filter terminals X2.1, X2.2 and
X2.3
Paralleling of frequency converters
If several frequency converters are to be connected to one
harmonic filter, the connection method is similar to the
connection described above. The supply terminals L1, L2 and
L3 of the frequency converters must be connected to the filter
terminals X2.1, X2.2 and X2.3.
NOTE
Use cables complying with local regulations.
Current in A Clamp Cable cross-
mains section
terminals
10 WDU 6
0.5-10 mm
14 WDU 6
0.5-10 mm
22 WDU 6
0.5-10 mm
29 WDU 6
0.5-10 mm
34 WDU 16
1.5-25 mm
40 WDU 16
1.5-25 mm
55 WDU 16
1.5-25 mm
66 WDU 35
2.5-50 mm
82 WDU 35
2.5-50 mm
96 WDU 50 N
10-70 mm
133 WDU 50 N
10-70 mm
171 WFF 70
2.5-95 mm
204 WFF 70
2.5-95 mm
251 WFF 300
25-300 mm
304 WFF 300
25-300 mm
325 WFF 300
25-300 mm
380 WFF 300
25-300 mm
480 WFF 300
25-300 mm
Table 6.1: 380 - 415 V, 50 and 60 Hz
AHF005/010 Design Guide
Main terminals
Cable end Torque in
Nm
2 cable end 1.6
sleeve
2
cable end 1.6
sleeve
2 cable end 1.6
sleeve
2
cable end 1.6
sleeve
2 cable end 2.4
sleeve
2
cable end 2.4
sleeve
2 cable end 2.4
sleeve
2
cable end 4.5
sleeve
2
cable end 4.5
sleeve
2 cable end 6
sleeve
2
cable end 6
sleeve
2 cable lug M8 12
2
cable lug M8 12
2
cable lug M16 60
2 cable lug M16 60
2 cable lug M16 60
2
cable lug M16 60
2
cable lug M16 60
®
MG.80.C3.02 - VLT is a registered Danfoss trademark
Paralleling of filters
If the mains input current of the frequency converter exceeds
the nominal current of the largest harmonic filter, several
harmonic filters can be paralleled to achieve the necessary
current rating – see Electrical Data tabels.
Supply voltage be connected to the terminals X1.1, X1.2 and
X1.3 of the filters. The frequency converter supply terminals
L1, L2 and L3 must be connected to the filters terminals X2.1,
X2.2 and X2.3
Terminals and cables
The following tabels show the terminal types, cable cross
section, tightening torque, etc.
Capacitor disconnect terminals
Clamp capaci- Cable cross-
tor disconnect section
terminals
WDU 2.5 2
0.5-4 mm
2
WDU 2.5
0.5-4 mm
WDU 2.5 2
0.5-4 mm
2
WDU 2.5
0.5-4 mm
WDU 10 2
1.5-16 mm
2
WDU 10
1.5-16 mm
WDU 10 2
1.5-16 mm
2
WDU 16
1.5-16 mm
2
WDU 16
1.5-16 mm
WDU 16 2
1.5-16 mm
2
WDU 16
1.5-16 mm
WDU 35 2
2.5-50 mm
2
WDU 35
2.5-50 mm
2
WDU 95 N
16-150 mm
WDU 95 N 2
16-150 mm
WDU 95 N 2
16-150 mm
2
WDU 95 N
16-150 mm
2
WDU 95 N
16-150 mm
Cable end Torque in
Nm
cable end sleeve 0.8
cable end sleeve 0.8
cable end sleeve 0.8
cable end sleeve 0.8
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 2.4
cable end sleeve 4.5
cable end sleeve 4.5
cable end sleeve 20
cable end sleeve 20
cable end sleeve 20
cable end sleeve 20
cable end sleeve 20
27
