Wiring - Danfoss VLT AHF005 Design Manual

How to Install
Current rating
380-415V, 50 and
60Hz
A
10
14
22
29
34
40
55
66
6 6
82
96
133
171
204
251
304
325
380
480
1) min. 50% of the nominal load

6.2.3 Wiring

Supply voltage must be connected to the terminals X1.1, X1.2 and X1.3. The frequency converter supply terminals L1, L2 and L3
must be connected to the filter terminals X2.1, X2.2 and X2.3
Paralleling of frequency converters
If several frequency converters are to be connected to one harmonic filter, the connection method is similar to the connection
described above. The supply terminals L1, L2 and L3 of the frequency converters must be connected to the filter terminals X2.1,
X2.2 and X2.3.
NOTE
Use cables complying with local regulations.
Paralleling of filters
If the mains input current of the frequency converter exceeds the nominal current of the largest harmonic filter, several
harmonic filters can be paralleled to achieve the necessary current rating – see Electrical Data tabels.
Supply voltage be connected to the terminals X1.1, X1.2 and X1.3 of the filters. The frequency converter supply terminals L1, L2
and L3 must be connected to the filters terminals X2.1, X2.2 and X2.3
Terminals and cables
The following tabels show the terminal types, cable cross section, tightening torque, etc.
34
AHF005/010 Design Guide
Current Danfoss
rating Contactors for
440-480V, AHF005 and Alternative
60Hz AHF010
A Type rating
10 CI 9
14 CI 9
19 CI 9
25 CI 9
31 CI 16
36 CI 16
48 CI 16
60 CI 61
73 CI 61
95 CI 61
118 CI 61
154 CI 61
183 CI 61
231 CI 110
291 CI 110
355 CI 110
380 CI 110
436 CI 141
MG.80.C4.02 - VLT
type AC3
Contactor
1) KVAr
1
2
4
6
7
7
9
11
15
17
22
29
36
44
51
58
66
88
®
is a registered Danfoss trademark
