The SMS plug-in snaps into an open slot in the front of the controller. The controller
provides power and communicates with the plug-in module over the backplane. A sample
CCW program is available at no additional cost with plug-in function block drivers and a
sample program provided in Structured Text, Ladder and Function Block languages.
Programmers may use these sample programs to create their own projects for sending and
receiving messages, alarms and machine status updates.
The front mounted coax connector allows for either a direct-mounted antenna or externally
mounted antenna (installed outside the panel or cabinet for better cellular reception).
Antennas must be ordered separately.
1.2 Package Contents
The following components are included with your ILX800-SMSG plug-in module.
Note: You will also need a SIM card and antenna (not included). For information on suitable antennas, please
see Installing an Antenna.
Qty. Part Name
1 ILX800-SMSG plug-in
module
Page 8 of 39
Part Number Part Description
ILX800-SMSG SMS Text Plug-in Module for GSM
Networks
ILX800-SMSG ♦ Micro800 Platform
SMS Text Plug-in Module for GSM Networks
