ILX800-SMSG ♦ Micro800 Platform
SMS Text Plug-in Module for GSM Networks
2 Setting Up the Controller Program
In This Chapter

The Sample Controller Program ............................................................13

Importing the Sample Program ..............................................................14

Configuring the Module's Slot Number ..................................................16

Entering a Test Phone Number .............................................................17

Connecting the Controller to Your PC ....................................................17

Downloading the Sample Program ........................................................17

Going Online with the Controller ............................................................20

Customizing Your Controller Program Logic ..........................................22
2.1 The Sample Controller Program
The sample controller program contains the program logic, function blocks, and variables
required to configure and operate the ILX800-SMSG plug-in module. It is provided in three
languages: Structured Text (ST), Ladder Diagram (LD), and Function Block Diagram (FBD).
Download the appropriate .7z import file from www.prosoft-technology.com. Save it to a
convenient location in your PC, such as Desktop or My Documents.
File Name
ILX800SMSG_v1_01_ST.7z
ILX800SMSG_v1_01_LD.7z
ILX800SMSG_v1_01_FBD.7z
Note: The sample controller program is intended to demonstrate the ILX800-SMSG plug-in module's full range
of capabilities, as a guide for creating your own application. The program features are provided in a modular
format, enabling the selection of features that will provide the optimum balance of usability, performance and
memory usage for your application.
ProSoft Technology, Inc.
August 24, 2016
Language
Structured Text
Ladder Diagram
Function Block Diagram
Controller memory usage (KB)
38
49
52
