ProSoft Technology ILX800-SMSG User Manual page 25

ILX800-SMSG ♦ Micro800 Platform
SMS Text Plug-in Module for GSM Networks
4 Enter up to two phone numbers in the Initial Value column. Do not enter any spaces,
parentheses or hyphens. (If CCW is online with the controller in debug mode, enter the
phone numbers in the Logical Value column.)
5 To enter an international number, use [+] followed by the country code and number.
Example: To enter a phone number in China, enter "+" followed by China's country code, which is 86. Then
enter the phone number (we will use 12345678901 for this example). The entry would look like this:
+8612345678901.
6 Save, build and download the program to the controller.
Note: You can also add a phone number to the Receiver List from a cell phone via a text message command.
See Text Message Commands.
3.2.2 Whitelist
The Whitelist can hold up to two phone numbers. If the Whitelist is enabled, the plug-in
module will only respond to text message commands from phone numbers on the Whitelist.
If the Whitelist is disabled, the plug-in module will respond to text message commands from
any phone number.
To enable or disable the Whitelist
1 Double-click the L
Project Organizer pane.
2 Click the header of the N
3 Find the Boolean variable CONFIG_
4 Enter TRUE or FALSE is the Initial Value column.
5 Save, build and download the program to the controller.
Note: The Whitelist can also be enabled or disabled from a cell phone via a text message command. See Text
Message Commands.
ProSoft Technology, Inc.
August 24, 2016
V icon for the PSFT_ILX800_SMSG program in the
OCAL ARIABLES
column to sort the variables alphabetically.
AME
WHITE
L E in the Name column.
IST NABLED
