6.3.2 Terminal assignment table, Joining station (XG2)

Digital
Function SysLink
I0 13
I1 14
I2 15
I3 16
I4 17
I5 18
I6 19
I7 20
Q0 1
Q1 2
Q2 3
Q3 4
Q4 5
Q5 6
Q6 7
Q7 8
24 V A 9+10
24 V B 21+22
GND A 11
GND A 12
GND B 23+24
Note
Cable jumpers are connected from emergency off to bit 1.5 for all standard PLC versions.
In the case of XG2, all signals are transmitted via a bus node which addresses the signals with
different protocols depending on the controller.
• For Siemens PLCs: ProfiNet,
• For Allen Bradley PLCs: Ethernet IP
© Festo Didactic 8064034
Color Designation
Gray-pink Slide retracted
Red-blue Slide advanced
White-green Gripper at bottom
Brown-green Gripper open
White-yellow
Brown-yellow
White-gray
Gray-brown
White Retract slide
Brown Advance slide
Green Gripper up
Yellow Open gripper
Gray
Pink
Blue
Red
Black 24 V power supply for outputs
White-pink 24 V power supply for inputs
Brown-pink 0 V power supply for outputs
Purple 0 V power supply for outputs
White-blue 0 V power supply for inputs
®
