6.2 Terminal assignment tables, Distributing/Conveyor station with signal column at the control panel

Digital (station XG1)
Function SysLink
I0 13
I1 14
I2 15
I3 16
I4 17
I5 18
I6 19
I7 20
Q0 1
Q1 2
Q2 3
Q3 4
Q4 5
Q5 6
Q6 7
Q7 8
24 V A 9+10
24 V B 21+22
GND A 11
GND A 12
GND B 23+24
42
Color Designation
Gray-pink Workpiece at beginning of conveyor
Red-blue Workpiece at middle of conveyor
White-green Workpiece not at end of conveyor
Brown-green
White-yellow Slide retracted
Brown-yellow Slide advanced
White-gray Magazine empty
Gray-brown
White Conveyor belt forward
Brown Conveyor belt reverse
Green Retract deflector
Yellow
Gray Advance slide
Pink
Blue
Red
Black 24 V power supply for outputs
White-pink 24 V power supply for inputs
Brown-pink 0 V power supply for outputs
Purple 0 V power supply for outputs
White-blue 0 V power supply for inputs
