Technical data
The weights given should be added to the weights for the relevant machine given in the
standard operating instructions!
Only the modified data is given.
Type
Cooling output at 2 l/min¹
Max. flow rate¹
Max. coolant output pressure¹
Dimensions L x W x H in mm
Weight
(¹) Machines with integrated welding torch cooling
5
Commissioning
5.1
General
Risk of injury from electric shock!
Contact with live parts, e.g. welding current sockets, is potentially fatal!
•
Follow safety instructions on the opening pages of the operating instructions.
•
Commissioning may only be carried out by persons who have the relevant expertise of
working with arc welding machines!
•
Connection and welding leads (e.g. electrode holder, welding torch, workpiece lead,
interfaces) may only be connected when the machine is switched off!
Damage due to the use of non-genuine parts!
The manufacturer's warranty becomes void if non-genuine parts are used!
•
Only use system components and options (power sources, welding torches, electrode
holders, remote controls, spare parts and replacement parts, etc.) from our range of
products!
Item No.:099-OW0008-EWM01
NOTE
301, 351, 421 K
1100 x 680 x 950
+18 kg
DANGER
CAUTION
Technical data
301, 351, 421, 521 D
1500 W
20 l/min
4.5 bar
+24 kg
General
7
